PLANET PWR-480-48 Power Supply Unit 480 W Blue, Grey

The PLANET PWR-480-48 is a high-performance DIN rail power supply unit delivering 480 W of reliable power with a 48 V DC output. Designed for industrial and networking applications, it ensures stable operation under demanding conditions.

Advantages

This power supply offers up to 89% efficiency, reducing energy waste and heat generation. Its free air convection cooling ensures silent operation and long-term reliability. With comprehensive protection features including overload, over voltage, short circuit, and over temperature, it safeguards connected equipment.

Suitable for

• Industrial automation systems
• Network switches and routers
• Security and surveillance equipment
• Any application requiring a robust 48 V DC power source

Key specifications

• Power Output: 480 W
• Output Voltage: 48 V DC (adjustable 48 ~ 55 V)
• Output Current: 10 A
• Input Voltage: 90 ~ 264 V AC / 127 ~ 370 V DC
• Input Frequency: 47 ~ 63 Hz
• Efficiency: Up to 89%
• Mounting: DIN Rail
• Protection: Overload, Over Voltage, Short Circuit, Over Temperature
• Cooling: Free Air Convection
• Operating Temperature: -20 to +70 °C
• Ripple & Noise: 150 mVp-p
• Isolation: I/P-O/P: 3KVAC, I/P-FG: 2KVAC, O/P-FG: 0.5KVAC
• Certifications: UL 508, TUV EN60950-1, CE, CB, RoHS
• Housing: Metal (Blue/Grey)

Recommendations

For optimal performance, ensure proper ventilation and mounting on a standard DIN rail. This power supply is ideal for powering PLANET networking devices and other 48 V DC equipment.
