Patch panel Rutenbeck 23810200

The Rutenbeck 23810200 patch panel provides organized Gigabit Ethernet connectivity using RJ-45 ports in a compact housing. With dimensions of 108 mm (width) × 56 mm (height) × 95 mm (depth) and a neutral grey finish, the unit is designed for space-constrained installations where reliable network termination and cable management are required. The panel is intended to be integrated into wall boxes, communication cabinets, or small distribution points to centralize network connections.

Advantages

The panel supports Gigabit Ethernet through RJ-45 connectors, enabling high-speed data transmission for local area networks. Its compact footprint allows installation in limited spaces while maintaining accessibility for patching and maintenance. The neutral grey color reduces visual impact in both residential and commercial environments. The product design focuses on straightforward cable organization and secure connector placement to minimize signal loss and physical strain on network cables.

Suitable for

Key specifications

How to use

Install the patch panel into the designated wall box or distribution enclosure following standard mounting procedures. Terminate the incoming permanent network cabling onto the back of the patch panel according to the relevant wiring standard (T568A or T568B), taking care to maintain pair integrity and correct conductor order. Plug patch cords into the front RJ-45 ports to connect devices or network switches. Ensure cable strain relief and maintain bend radius to preserve signal quality.

Recommendations

For reliable Gigabit performance, use quality Cat5e or higher cabling and ensure terminations are performed with appropriate tools and testing equipment. Keep patch cords and permanent links separated where possible to simplify troubleshooting and maintenance.
