Keystone module Rutenbeck 17000600

The Rutenbeck 17000600 Keystone module is a flat, white connector module designed for easy integration into structured cabling panels and wall plates. It provides a single BNC connection in a compact form factor that supports video and RF signal transmission where a BNC interface is required. The lightweight construction and small footprint make it suitable for installations that demand tidy, low-profile cabling solutions.

Advantages

The module's flat construction enables a discreet installation in keystone-compatible frames and outlets while maintaining reliable electrical contact for BNC connections. Its compact size and light weight simplify handling and mounting in both new installations and retrofit projects. The white finish ensures a neutral appearance that blends with standard faceplates and interior environments.

Suitable for

Key specifications

How to use

Insert the keystone module into a compatible keystone outlet or faceplate until it snaps into place. Connect the incoming coaxial cable to the BNC connector, ensuring a secure mechanical and electrical connection. For panel mounting, align the module with the keystone opening and press until the latch engages. Verify signal integrity after installation by testing with the appropriate video or RF equipment.

Recommendations

Use the module in environments where a BNC interface is specified and pair it with compatible keystone frames and faceplates. Avoid excessive bending or mechanical stress on connected coaxial cables to maintain signal quality. For best results, perform a signal test after installation and follow local cabling standards for grounding and shielding.
