Network Video Recorder LEVELONE NVR-0411 — 32-channel, 4096×2160 max, 10 TB SATA, PoE 16 W/port, 17x RJ-45, USB 2x2

The LevelOne NVR-0411 is a network video recorder that supports up to 32 IP cameras with recording, live view and playback at resolutions up to 4096 x 2160 (4K) using H.265/H.264 compression. It provides 16 built-in PoE ports for camera power, four HDD bays with up to 10 TB total SATA storage, and remote monitoring via web browsers (IE11, Chrome, Firefox, Safari, Edge) or the LevelOne Guarding Vision mobile app. Guarding Vision CMS is included free and can centrally manage multiple NVRs and up to 256 channels for larger deployments.

Advantages

The NVR-0411 combines multi-channel recording and high-resolution support with integrated PoE ports, simplifying installation and cabling. Its support for H.265 compression reduces storage and bandwidth requirements while maintaining image quality. A four-bay HDD design with 10 TB maximum capacity and compatibility with ONVIF/ISAPI cameras ensures flexible storage and broad camera interoperability. The included Guarding Vision CMS enables centralized management of many devices without additional license costs.

Suitable for

• Small and medium business video surveillance
• Retail stores and branches requiring centralized monitoring
• Office buildings and multi-camera installations
• Sites needing up to 4K local display and multi-site management

Key specifications

• Model: LevelOne NVR-0411
• Video input channels: 32 channels
• Maximum resolution: 4096 x 2160 pixels (up to 12 MP)
• Simultaneous playback channels (via CMS): up to 256 channels
• Video compression: H.265, H.264
• Built-in PoE ports: 16 (PoE power per port up to 16 W)
• HDD bays: 4, interface: SATA, maximum total capacity: 10 TB
• USB ports: USB 2.0 x2, USB 3.x x1 (product attributes also list USB 3.2 Gen1 Type-A quantity 2)
• Ethernet (RJ-45) ports: 17
• Local display: 4K2K HDMI
• Input bandwidth: 256 Mbit/s; Output bandwidth: 160 Mbit/s
• Face recognition: supports facial recognition with up to 16 face libraries and up to 20,000 face pictures
• Compatibility: ONVIF (Profile S/G) and ISAPI-compliant cameras
• Power consumption (max): 200 W; typical: 20 W
• Colours: Black, Grey
• Weight: 5 kg

How to use

Install the NVR in a rack or on a stable surface and connect IP cameras to the built-in PoE ports or to your network switches. Install SATA HDDs into the four bays if on-site storage is required, then power on the device. Access the web interface using a supported browser (IE11, Chrome V57+, Firefox V52+, Safari V12, Edge) or use the Guarding Vision mobile app for remote viewing on iOS/Android. Configure recording schedules, encoding settings (H.265/H.264), and network parameters via the web GUI. If needed, add the NVR to Guarding Vision CMS to manage multiple devices centrally and configure user accounts and permissions.

Recommendations

For reliable continuous recording, install enterprise-grade SATA hard drives designed for surveillance, monitor HDD health regularly, and configure motion or event-based recording to optimize storage. Ensure the NVR firmware and Guarding Vision CMS app are kept up to date and limit administrative access to secure accounts. When deploying many cameras, verify network bandwidth and use segmented VLANs or dedicated switches for PoE cameras to maintain performance.
