Monitor Ernitec 0070-24110-M-L 24 inch LCD Display 1920x1080

This industrial-grade 10" TFT-LED monitor is built for continuous 24/7 operation and delivers a physical resolution of 1280 x 800 with a 16:9 aspect ratio. The panel provides wide 178° viewing angles, 16.7 million colors and built-in stereo speakers, while supporting PAL/NTSC/SECAM video formats and multiple inputs for flexible installation.

Advantages

The monitor offers a fast 5 ms response time to reduce motion blur, 3D digital filtering and video noise reduction for clearer images, and LED backlight technology for consistent brightness. It supports HDMI 2.0, VGA and BNC I/O, has low power consumption (≤8W) and a wide operating temperature range (-30 to +85°C). The unit includes an industrial PSU, mounting screws and a quick start guide, and features a long MTBF of 50,000 hours.

Suitable for

• Industrial control rooms and machine interfaces
• Security and surveillance monitoring (DVR/CCTV integration)
• Public information displays and kiosks
• Transport and vehicle-mounted systems requiring wide temperature range

Key specifications

• Screen size: 10 inches; Active area: 162 × 121.5 mm
• Resolution: 1280 × 800; Aspect ratio: 16:9; Pixel pitch: 0.2025 × 0.2025 mm
• Brightness: 250 nits; Contrast ratio: 500:1; Colors: 16.7 million
• Viewing angle: 178° horizontal / 178° vertical; Response time: 5 ms
• Inputs/outputs: HDMI 2.0 ×1, VGA ×1, BNC in ×2, BNC out ×1; Speakers: 2 × 3W
• Power: DC 12V, 50/60 Hz; Power consumption: ≤8W
• Operating temperature: -30 to +85 °C; MTBF: 50,000 hours
• Mounting: VESA 75 × 75; Weight: 3.5 kg

How to use

Mount the monitor using the VESA 75×75 pattern or place it on a compatible bracket. Connect a 12V DC industrial power supply (included) and attach video sources via HDMI, VGA or BNC connectors depending on your system. Use the on-screen display (OSD) menu to adjust brightness, contrast, position, phase and color, and select the appropriate input and video standard (PAL/NTSC/SECAM). For surveillance use, connect cameras to the BNC inputs and route output through the BNC output if required.

Recommendations

Install the monitor in a ventilated location and avoid prolonged exposure to direct sunlight. Use recommended industrial-grade cabling and secure mounting to maintain stable operation in demanding environments.
