MIBOXER D4-CX LED DMX 4-Channel Controller DMX Series

The MIBOXER D4-CX is a professional 4-channel DMX512 LED controller designed for RGBW, RGB, CCT, and single-color LED strips and modules. It provides precise dimming control (0-100%) and supports constant voltage LED loads up to 480W (24V). With DIP switch address setting and robust protection features, it is ideal for stage, architectural, and commercial lighting installations.

Advantages

Reliable DMX512 control with 4 independent channels, each capable of 5A output (total 20A). Wide input voltage range (DC 12-24V) and high efficiency. Built-in overload, short circuit, and reverse polarity protection ensure long-lasting performance. Compact ABS housing with screw terminals for easy wiring.

Suitable for

• RGBW LED strip lighting
• RGB LED modules
• CCT tunable white installations
• Single-color LED accent lighting
• Stage and theater lighting
• Architectural and commercial lighting projects

Key specifications

• Control Protocol: DMX512
• Number of Channels: 4
• Input Voltage: DC 12V-24V
• Output Current per Channel: Max 5A
• Total Output Current: Max 20A
• Max Output Power (12V): 240W
• Max Output Power (24V): 480W
• Output Type: Constant Voltage
• Dimming Range: 0-100%
• DMX Address Setting: DIP Switches
• Operating Temperature: -20°C to 60°C
• Connection Type: Screw Terminals
• Compatible LED Types: RGBW, RGB, CCT, Single Color
• Protection Features: Overload, Short Circuit, Reverse Polarity
• Housing Material: ABS Plastic

Recommendations

For optimal performance, use a suitable DC power supply (12V or 24V) and ensure proper DMX cabling. The D4-CX is compatible with standard DMX controllers and supports daisy-chaining of multiple units.
