LevelOne 6-Port Gigabit Industrial Switch, 1 x SFP, 1 x SFP/RJ45 Combo, -40°C to 75°C, DIN-Rail

LevelOne 6-Port Gigabit Industrial Switch, 1 x SFP, 1 x SFP/RJ45 Combo, -40°C to 75°C, DIN-Rail
LevelOne 6-Port Gigabit Industrial Switch, 1 x SFP, 1 x SFP/RJ45 Combo, -40°C to 75°C, DIN-Rail
LevelOne 6-Port Gigabit Industrial Switch, 1 x SFP, 1 x SFP/RJ45 Combo, -40°C to 75°C, DIN-Rail
LevelOne 6-Port Gigabit Industrial Switch, 1 x SFP, 1 x SFP/RJ45 Combo, -40°C to 75°C, DIN-Rail
R4,952
LevelOne IES-0600 Industry Ethernet Switch provides 4 ports 10/100/1000Base plus 2 port Gigabit SFP to enable high speed network at mission-critical environment. With the industrial standard DIN-rain mount; this switch can be easily installed in the cabinet, plus the clearly visible status LEDs prov... Read More
Stock 26 Code 2452979 Brand LEVELONE Model IES-0600 Warranty 2 Years

Shipping & Returns

Estimated delivery Monday, October 12
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
LevelOne IES-0600 Industry Ethernet Switch provides 4 ports 10/100/1000Base plus 2 port Gigabit SFP to enable high speed network at mission-critical environment. With the industrial standard DIN-rain mount; this switch can be easily installed in the cabinet, plus the clearly visible status LEDs provide simple monitoring of port link activity. Moreover, the SFP slots support pluggable modules that enabling you to choose from a variety of transceivers.

- 4 10/100/1000Base-T ports
- 1 Gigabit Combo + 1 Gigabit SFP(100/1G) slot
- 1000 Mbps-Full-duplex, 10/100Mbps-Full/Half-duplex,
- Auto-Negotiation, Auto-MDI/MDIX
- 40°C to 75°C (-40°F to 167°F) operating temperature range
- DIN-Rail mount installation
- Metal case design and compliant with IP30 standard

LevelOne 6-Port Gigabit Industrial Switch, 1 x SFP, 1 x SFP/RJ45 Combo, -40°C to 75°C, DIN-Rail. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 4. Full duplex. MAC address table: 1024 entries, Switching capacity: 12 Gbit/s. Networking standards: IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z. Wall mountable

Specifications
10G support
No
Auto MDI/MDI-X
Yes
Auto-negotiation
Yes
Basic switching RJ-45 Ethernet ports quantity
4
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Certification
FCC Part 15 Subpart B Class A CE EN 55022 Class A EN61000-4-2 (ESD) Level 3 EN61000-4-3 (RS) Level 3 EN61000-4-4 (EFT) Level 3 EN61000-4-5 (Surge) Level 3 EN61000-4-6 (CS) Level 3 EN61000-4-8 (Magnetic Field) Level 3 UL508 (Pending) EN 50121-4 (Pending) IEC 60068-2-27 IEC 60068-2-32 IEC 60068-2-6 UL 508
Country of origin
Taiwan
Depth
105 mm
DIN rail mounting
Yes
Flow control support
Yes
Full duplex
Yes
Harmonized System (HS) code
85176990
Height
38 mm
Housing material
Metal
Input voltage
5 - 56 V
International Protection (IP) code
IP30
Jumbo frames
10000
LED indicators
Activity, Link, Power
MAC address table
1024 entries
Networking standards
IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Operating relative humidity (H-H)
5 - 95%
Operating temperature (T-T)
-40 - 75 °C
Package depth
165 mm
Package height
65 mm
Package type
Box
Package weight
120 g
Package width
215 mm
Packet buffer memory
1 MB
Packet forwarding rate (1 Gbps)
1488000 pps
Packet forwarding rate (10 Mbps)
14880 pps
Packet forwarding rate (100 Mbps)
148000 pps
Power over Ethernet (PoE)
No
Power protection features
Overload, Reverse polarity
Product colour
Black
Quick start guide
Yes
SFP module slots quantity
1
Storage relative humidity (H-H)
5 - 95%
Storage temperature (T-T)
-40 - 85 °C
Store-and-forward
Yes
Switching capacity
12 Gbit/s
Terminal block port
Yes
Wall mountable
Yes
Weight
720 g
Width
40 mm

Leaflet

Open Leaflet
