Iiyama ProLite T1731SR-W5 17 inch SXGA 5-Wire Resistive Touch LED Monitor, Black

In point-of-sale terminals, kiosks, and industrial control panels, a display that fails after a few thousand touches or cannot be read in bright ambient light can bring operations to a halt. The Iiyama ProLite T1731SR-W5 solves this with a 17-inch 5-wire resistive touchscreen built for continuous public and commercial use. Its 3H-hardness surface resists scratches, while the 250 cd/m² brightness and 1000:1 contrast keep the SXGA image clear even under shop lighting. The stand tilts from -5° all the way to 90°, so the screen can lie almost flat for countertop service or stand upright for wall-mounted interaction via the 100 x 100 mm VESA pattern.

Who is it for

This monitor is intended for system integrators, retail IT managers, and industrial automation engineers who need a reliable touch interface for POS, self-service, hospitality, or light manufacturing. It is also suitable for digital signage in reception areas, medical carts, and control rooms where space is limited and touch input must work with gloved hands, credit cards, or styluses.

Main features

• 17-inch TN LED panel with native SXGA 1280 x 1024 resolution and 5:4 aspect ratio for legacy and business applications.
• 5-wire resistive touch technology: accurate, pressure-sensitive, works with finger, glove, pen, or card; no driver calibration drift.
• Dual video inputs: DVI-D and D-Sub (VGA) for flexible connection to modern and legacy PCs or thin clients.
• Built-in stereo speakers (2 x 1 W) and 3.5 mm audio input for basic sound.
• USB Type-B upstream port for touch interface connectivity.
• Wide tilt range from -5° to 90° for ergonomic positioning; VESA 100 x 100 mm mount for wall or arm installation.

Specifications

• Display diagonal: 17" (43 cm)
• Panel type: TN LED
• Native resolution: 1280 x 1024 (SXGA)
• Aspect ratio: 5:4
• Brightness: 250 cd/m²
• Contrast ratio: 1000:1 static
• Response time: 5 ms
• Viewing angles: 170° horizontal / 160° vertical
• Touch technology: 5-wire resistive, surface hardness 3H
• Video inputs: DVI-D, D-Sub (VGA)
• Audio: 3.5 mm input, 2 x 1 W speakers
• USB: 1 x USB Type-B (upstream, for touch)
• Power consumption: 20 W typical
• Colour support: 16.7 million colours
• Operating temperature: 0°C to 40°C
• Certifications: CE, TÜV-GS, VCCI-B, CU, cULus, RoHS, ErP, WEEE

Tips

For gloved-hand operation in industrial or medical environments, the resistive touch panel responds to pressure without needing a bare finger. To maintain accuracy, avoid using sharp objects; the 3H surface is scratch-resistant but not scratch-proof. When mounting on a VESA arm, ensure the arm supports the monitor's weight and allows the desired tilt range. Use the DVI-D input for digital signal quality when connecting to modern PCs; the VGA input is ideal for legacy systems.
