HPE G3 Basic PDU 3.6kVA 1U Half-Height Rack PDU

The HPE G3 Basic PDU 3.6kVA 1U Half-Height Rack PDU (P59407-B21) is a reliable power distribution unit designed for HPE ProLiant servers and HPE racks. It provides efficient power distribution with a 3.6 kVA capacity, ideal for data centers and server rooms requiring basic power management.

Advantages

This PDU offers a compact half-height form factor that saves valuable rack space. It features a robust design with overload protection via an integrated circuit breaker, ensuring safe operation. The unit supports both horizontal (1U) and vertical (0U) mounting options for flexible installation.

Suitable for

• HPE ProLiant servers and HPE racks
• Data centers requiring basic power distribution
• IT environments needing reliable 1-phase power delivery

Key specifications

• PDU Type: Basic
• Form Factor: Half-Height (HH), 1U Rack-mountable
• Power Capacity: 3.6 kVA
• Input Voltage: 200-240V AC
• Input Current: 16 A
• Input Connector: 1 x IEC 60320 C20
• Output Connectors: 6 x IEC 60320 C13, 1 x IEC 60320 C19
• Phases: 1-Phase
• Mounting Options: Horizontal (1U) or Vertical (0U)
• Overload Protection: Yes (via integrated circuit breaker)
• Power Cord Included: No
• Operating Temperature: 0 to 45 °C (32 to 113 °F)
• Operating Humidity: 5 - 95% (non-condensing)
• Color: Black

Recommendations

For optimal performance, pair this PDU with HPE ProLiant servers and use appropriate power cords (not included). Ensure proper ventilation and adhere to the specified operating conditions.
