Hager FZ360 Flush-Mounted Distribution Board 39 Modules White

The Hager FZ360 is a high-quality flush-mounted distribution board designed for residential and light commercial electrical installations. Part of the Volta series, this enclosure offers 39 modules across 3 rows, providing ample space for circuit protection devices. Manufactured from halogen-free plastic with a white RAL 9010 finish, it ensures safety and durability.

Advantages

Easy installation with pre-cut knockouts for cable entries. The reversible door option allows flexible mounting. Terminal blocks for N and PE are included, simplifying wiring. Complies with EN 60439-3 and EN 61439-3 standards.

Suitable for

• Residential electrical distribution
• Light commercial applications
• Flush-mounted installations in walls

Key specifications

• Mounting Type: Flush-mounted
• Number of Rows: 3
• Total Modules: 39 (13 per row)
• Protection Class: IP30 (without door)
• Impact Protection: IK07
• Material: Plastic, halogen-free
• Colour: White (RAL 9010)
• Glow Wire Test: 850 °C
• Insulation Class: Class II
• Standards: EN 60439-3, EN 61439-3
• Terminal Blocks: N and PE included
• Operating Temperature: -5 °C to +40 °C
• Installation Depth: 72 mm
• Rated Voltage: 400V AC

Recommendations

For optimal performance, use with Hager circuit breakers and accessories. Ensure proper installation by a qualified electrician.
