HAGER SPA931 SPD Surge Protective Device T1+T2 B+C 4P 4M 12.5/50kA 1.5kV TN-S

The HAGER SPA931 is a high-performance surge protective device (SPD) designed to protect electrical installations against transient overvoltages. Combining Type 1 and Type 2 protection (Class B+C), it is suitable for main distribution boards in TN-S systems. With a maximum discharge current of 50kA and a voltage protection level of 1.5kV, it ensures reliable protection for sensitive equipment.

Advantages

Combined Type 1+2 protection reduces installation space and cost. High surge capacity (12.5/50kA) handles direct lightning strikes and switching surges. Compact 4-module design fits standard DIN rail enclosures.

Suitable for

• Main distribution boards in TN-S earthing systems
• Commercial and industrial buildings requiring high surge protection
• Protection of sensitive electronic equipment against lightning and switching surges

Key specifications

• Brand: HAGER
• Model: SPA931
• Type: Surge Protective Device (SPD)
• Protection class: Type 1+2 (Class B+C)
• Number of poles: 4P
• Number of modules: 4M
• Maximum discharge current (Imax): 50kA
• Nominal discharge current (In): 12.5kA
• Voltage protection level (Up): 1.5kV
• System: TN-S
• Product colour: White

Recommendations

For optimal protection, install the SPA931 at the origin of the electrical installation. Ensure proper coordination with downstream Type 3 SPDs. Always follow local wiring regulations and manufacturer instructions.
