Grothe 360° Motion Detector White (94532)

Detecting movement in a room often means choosing between coverage and discretion. The Grothe 94532 solves this with a flush-mounted 360° PIR sensor that blends into the ceiling while monitoring the entire area below.

Who is it for

Electricians and homeowners who need reliable, automatic lighting control in corridors, bathrooms, or storage rooms. It suits anyone wanting a discreet, ceiling-mounted detector with adjustable sensitivity and timing.

Main features

• 360° passive infrared detection for full-room coverage
• Flush ceiling mounting with a compact 90 mm visible diameter
• Adjustable twilight threshold from 3 to 2000 lux
• Adjustable switch-off delay from 10 seconds to 15 minutes
• Switches loads up to 2000 W resistive or 1000 VA inductive
• White UV-stabilised polycarbonate housing for durability

Specifications

• Detection angle: 360°
• Detection range: up to 8 m diameter at 2.5 m mounting height
• Mounting height: 2.0 – 4.0 m
• Power supply: 230 V AC, 50 Hz
• Switching capacity: 2000 W (ohmic), 1000 VA (inductive)
• Twilight setting: 3 – 2000 lux
• Time setting: 10 s – 15 min
• Standby consumption: < 0.5 W
• Protection class: IP20
• Operating temperature: -20 °C to +40 °C
• Installation cut-out: 65 mm diameter
• Installation depth: 38 mm
• Product diameter: 90 mm
• Material: UV-stabilised polycarbonate
• Colour: White

Tips

For best coverage, install the detector at a height between 2.5 and 3 metres in the centre of the room. Avoid placing it near air vents, heat sources, or direct sunlight, as these can affect PIR performance.
