Wired PIR Motion Detector SATEL SLIM-DUAL-LUNA-PET — detection up to 13 m, AC supply, 100 mA, compact wall mount (62×42×137 mm)

The SATEL SLIM-DUAL-LUNA-PET is a wired PIR motion detector designed for indoor and sheltered outdoor use. It combines passive infrared sensing and dual-technology features to provide reliable detection up to 13 m across a 90° field of view. The detector is powered from a 12 V DC supply and draws approximately 100 mA, while its compact wall-mount housing (62 × 42 × 137 mm) simplifies installation in entrances, corridors and perimeter points.

Advantages

The dual-technology approach reduces false alarms by verifying PIR signals, improving stability in environments with pets or variable ambient conditions. Low current consumption and standard 12 V DC power make the device compatible with common alarm control panels. Its compact dimensions and wall-mount form factor enable unobtrusive placement in residential and commercial spaces.

Suitable for

• Perimeter protection and exterior sheltered zones
• Entrance and corridor monitoring
• Integration with wired alarm systems and control panels
• Areas with small pets where false alarm reduction is required

Key specifications

• Detection technology: Passive Infrared (PIR) with dual-technology filtering
• Detecting area: up to 13 m range, coverage approximately 12 m × 13 m at 90°
• Power supply: 12 V DC
• Current consumption: ~100 mA
• Operating temperature range: -10°C to +55°C
• Mounting type: compact wall mount
• Dimensions: 62 × 42 × 137 mm

How to use

Mount the detector on a stable wall surface at the recommended height for your application and orient it so the protected area falls within the 90° field of view. Connect the unit to a compatible 12 V DC alarm control panel or power supply following the system wiring diagram and applicable safety standards. After powering the detector, perform a walk-test across the protected zone to confirm reliable detection up to 13 m and adjust sensitivity or masking if the system supports these settings.

Recommendations

Install the detector away from direct heat sources, air vents and reflective surfaces to minimize false triggers. When protecting areas with pets, position the detector to avoid direct detection zones near floor level and follow manufacturer guidance on pet immunity settings. Use professional calibration and testing after installation to ensure optimal integration with your wired alarm system.
