Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX

Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX
Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX
Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX
Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX
36 mo.
Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX
Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX
Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX
Motherboard GIGABYTE B840M D2H, AMD Ryzen 9000, Socket AM5, Micro ATX
R2,349
GIGABYTE motherboards from the AORUS, AERO and GIGABYTE series provide a reliable foundation for desktop PCs. Designed for varied users — gamers, content creators and professionals — these boards combine modern layouts, robust power delivery and compatibility with current CPUs and components to supp... Read More
Stock 9 Code 111200 Brand GIGABYTE Model B840M D2H Warranty 3 Years

Shipping & Returns

Estimated delivery Tuesday, October 6
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

GIGABYTE motherboards from the AORUS, AERO and GIGABYTE series provide a reliable foundation for desktop PCs. Designed for varied users — gamers, content creators and professionals — these boards combine modern layouts, robust power delivery and compatibility with current CPUs and components to support stable performance for everyday and intensive tasks.

Advantages

The AORUS, AERO and GIGABYTE series offer stable power management, extensive connectivity options and durable components. Their layouts are optimized for cooling and component installation, while integrated features such as multi-GPU support, high-speed memory compatibility and modern I/O ports improve system versatility and upgradeability.

Key specifications

  • Form factors: various (ATX, mATX, ITX) depending on model
  • CPU support: compatible with current Intel and AMD sockets depending on model
  • Memory: multi-channel DDR4/DDR5 support depending on model
  • Storage: M.2 slots and SATA ports for SSDs and HDDs
  • Expansion: PCIe x16 and additional PCIe slots for GPUs and cards
  • Networking: onboard Ethernet and optional Wi-Fi modules on selected models
  • USB: multiple USB-A and USB-C ports including high-speed standards

How to use

Select the specific model that matches your CPU socket and desired feature set, install the CPU, memory and cooling according to the motherboard manual, connect storage and power supply, then install the operating system and drivers provided by GIGABYTE. Follow standard anti-static precautions and confirm BIOS/UEFI settings for optimal performance.

Recommendations

Choose a model that matches your case size and power requirements; consult the official GIGABYTE specifications for exact socket compatibility and supported memory speeds before purchase.

Key Highlights
  • X3D Turbo Mode to unleash new era gaming performance
  • AMD Socket AM5 : Supports AMD Ryzen 9000 / 8000 / 7000 Series Processors
  • Digital 5+2+2 phases VRM solution
  • Dual Channel DDR5 : 2*DIMMs with AMD EXPO Memory Module Support
  • EZ-Latch : PCIe x16 Slot with Quick Release Design
  • Friendly UI : Multi-Theme, AIO Fan Control, and Q-Flash Auto Scan in BIOS and SW
  • Ultra-Fast Storage : 2*M.2 slots, including 1* PCIe 4.0 x4
  • Fast Networking : 2.5GbE LAN
  • AMD Socket AM5 AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
  • PC micro ATX AMD B840 Realtek ALC897 7.1 channels
  • DDR5-SDRAM 2 DIMM Maximum internal memory: 128 GB
  • HDD & SSD M.2, PCI Express 4.0, SATA III RAID support Number of storage drives supported: 6
  • BIOS type: UEFI AMI 256 Mbit ACPI version: 5.0 Clear CMOS jumper
  • 2.5 Gigabit Ethernet
Specifications
1st M.2 highest PCI Express generation
4.0
1st M.2 largest key size
2580
2nd M.2 highest PCI Express generation
3.0
2nd M.2 largest key size
2280
ACPI version
5.0
ATX Power connector (24-pin)
Yes
Audio chip
Realtek ALC897
Audio output channels
7.1 channels
Batteries included
Yes
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
Battery weight
3 g
BIOS memory size
256 Mbit
BIOS type
UEFI AMI
Bundled software
Norton® Internet Security (OEM version) LAN bandwidth management software
Clear CMOS jumper
Yes
Compatible processor series
AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Component for
PC
Cooling type
Passive
CPU fan connector
Yes
Depth
244 mm
Desktop Management Interface (DMI) version
2.7
DirectX version
12.0
DVI-D ports quantity
0
ECC сompatibility
Non-ECC
EPS power connector (8-pin)
Yes
Ethernet interface type
2.5 Gigabit Ethernet
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Front panel audio connector
Yes
Front panel connector
Yes
HDCP
Yes
HDMI ports quantity
1
HDMI version
2.1
Headphone outputs
1
Height
35 mm
LAN controller
Realtek RTL8125
Line-in
Yes
Lithium weight per battery
0.07 g
Maximum internal memory
128 GB
Maximum internal memory per slot
64 GB
Maximum resolution
4096 x 2160 pixels
Memory channels
Dual-channel
Memory slots type
DIMM
Microphone in
Yes
Motherboard chipset
AMD B840
Motherboard chipset family
AMD
Motherboard form factor
micro ATX
Number of battery cells
1
Number of chassis fan connectors
1
Number of CPU fan connectors
2
Number of EPS power connectors (8-pin)
1
Number of HDDs supported
4
Number of M.2 (M) slots
2
Number of memory slots
2
Number of RGB LED pin headers
3
Number of SATA III connectors
4
Number of storage drives supported
6
Number of water pump connectors
1
Package depth
265 mm
Package height
54 mm
Package weight
1.03 kg
Package width
265 mm
Parallel processing technology support
Not supported
PC health monitoring
Fan, Temperature, Voltage, Water cooling
PCI Express x16 (Gen 3.x) slots
1
PCI Express x16 (Gen 4.x) slots
1
Power source type
ATX
Processor manufacturer
AMD
Processor socket
Socket AM5
Product colour
Dark brown
Products per shipping (inner) case
1 pc(s)
PS/2 ports quantity
1
RAID levels
0, 1, 10
RAID support
Yes
RGB LED pin header
Yes
Screws included
Yes
Supported memory clock speed (max)
7600 MHz
Supported memory clock speeds
7600,7200,7000,6800,6666,6600,6400,6200,6000,5600,5200,4800,4400 MHz
Supported memory types
DDR5-SDRAM
Supported processor sockets
Socket AM5
Supported storage drive interfaces
M.2, PCI Express 4.0, SATA III
Supported storage drive types
HDD & SSD
System Management BIOS (SMBIOS) version
2.7
TPM connector
Yes
Unbuffered memory
Yes
USB 2.0 connectors
2
USB 2.0 ports quantity
4
USB 3.2 Gen 1 (3.1 Gen 1) connectors
1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
VGA (D-Sub) ports quantity
0
Warranty period
3 year(s)
Weight
940 g
Wi-Fi
No
Width
244 mm
Windows operating systems supported
Windows 10 x64, Windows 11 x64
