Fitting by ek water blocks model — brass black height 7 mm diameter 16.5 mm

EK-Quantum Torque Micro Extender Static MF 7 - Black is a compact, small-diameter male+female G1/4" threaded extender designed for custom PC liquid-cooling loops. Machined from brass with a Satin Black finish and sealed with EPDM O-rings, this 7 mm high, 16.5 mm diameter extender is used to move or lengthen a G1/4" port on a block, radiator or other cooling component to improve accessibility and reduce tight bends or hard-to-reach fittings.

Advantages

The extender provides a durable, corrosion-resistant connection thanks to its brass construction and EPDM sealing. Its small form factor allows installation in cramped spaces or where ports are closely spaced, helping to simplify tube routing without adding a rotatable joint (this is a static, non-revolvable extender). The Satin Black finish matches many builds while the Torque family design ensures compatibility with G1/4" fittings.

Suitable for

• Extending G1/4" ports on water blocks, radiators, pumps or reservoirs
• Improving access where port spacing is tight or clearance is limited
• Reducing sharp tubing bends and easing installation in compact PC cases
• Use in custom liquid-cooling loops requiring small-diameter static extenders

Key specifications

• Brand: ek water blocks
• Model / MPN: 3831109827529
• EAN: 3831109827529
• Thread: G1/4" male + female
• Type: Static (non-revolvable) extender
• Material: CNC machined brass
• Finish: Satin Black
• Sealing: EPDM O-rings
• Height: 7 mm
• Diameter: 16.5 mm

How to use

Screw the male end of the extender into the G1/4" port of the component (block, radiator, pump or reservoir) until the O-ring seats to form a seal, then attach the desired G1/4" fitting or adapter to the female end. Ensure threads are aligned and hand-tighten; use appropriate tools only if necessary and avoid over-tightening to prevent damage to threads or O-rings. Verify there are no leaks after system fill and pressure test according to your cooling loop procedures.

Recommendations

Recommended for builders who need to shift or lengthen G1/4" ports in confined spaces. Not suitable when a rotatable (revolving) connection is required; choose a rotary extender if rotation is needed. Check compatibility with existing G1/4" fittings and perform a leak test after installation.
