Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey

Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
60 mo.
Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
R44,743
The Epson EB-685Wi is an ultra short throw interactive projector with 3,500 ANSI lumens brightness and WXGA (1280×800) resolution. Its ultra-short-throw design lets you project large images from a very short distance with reduced shadows and glare, while 3LCD technology provides balanced white and c... Read More
Stock 11 Code 1189068 Brand EPSON Model V11H741040 Warranty 5 Years

Shipping & Returns

Estimated delivery Thursday, October 8
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival

The Epson EB-685Wi is an ultra short throw interactive projector with 3,500 ANSI lumens brightness and WXGA (1280×800) resolution. Its ultra-short-throw design lets you project large images from a very short distance with reduced shadows and glare, while 3LCD technology provides balanced white and colour light output for vivid, clear images. The projector supports split-screen display, optional wireless connectivity via the iProjection app and dual-pen interactivity for simultaneous annotation.

Advantages

High brightness and 3LCD image processing deliver bright, natural colours and clear images even in well-lit rooms. The dual-pen functionality enables two users to annotate at the same time with different pen attributes. Ultra-short-throw optics minimise shadows and glare when presenting from close range. Long lamp life in eco mode increases reliability and reduces maintenance intervals.

Suitable for

  • Classroom lessons and interactive teaching
  • Corporate meeting rooms and presentations
  • Collaborative workshops and training sessions
  • Spaces where a large image is needed from a short throw distance

Key specifications

  • Brightness: 3,500 ANSI lumens
  • Native resolution: WXGA (1280×800)
  • Projection technology: 3LCD
  • Contrast ratio: 14,000:1
  • Lamp life: up to 10,000 hours (eco mode)
  • Weight: 5.9 kg
  • Fixed focal length: 3.7 mm (ultra short throw)
  • Screen size compatibility: approx. 1524–2540 mm
  • Colour: White / Grey

How to use

Place the EB-685Wi close to the projection surface according to the ultra-short-throw placement guidelines so it produces a large image with minimal shadows. Connect your source device via HDMI or enable optional wireless projection using the iProjection app on compatible smart devices and Chromebooks. Use the interactive pens to annotate directly on the projected image; two pens can be used simultaneously for collaborative work. Adjust focus manually as needed for a sharp image.

Recommendations

For best results in classrooms and meeting rooms, use the projector in eco mode to extend lamp life, position it on or near the short-throw mount to minimise presenter shadows, and enable split-screen when you need to show two content sources simultaneously.
Key Highlights
  • Classroom lessons and interactive teaching
  • Corporate meeting rooms and presentations
  • Collaborative workshops and training sessions
  • Spaces where a large image is needed from a short throw distance
  • Brightness: 3,500 ANSI lumens
  • Native resolution: WXGA (1280×800)
  • Projection technology: 3LCD
  • Contrast ratio: 14,000:1
  • Lamp life: up to 10,000 hours (eco mode)
  • Weight: 5.9 kg
  • Fixed focal length: 3.7 mm (ultra short throw)
  • Screen size compatibility: approx. 1524–2540 mm
  • Colour: White / Grey
Specifications
3D
No
AC (power) in
Yes
AC input frequency
50 - 60 Hz
AC input voltage
100-240 V
Audio (L/R) in
1
Built-in display
No
Built-in speaker(s)
Yes
Bundled software
Easy Interactive Tools, EasyMP Multi PC Projection, Epson Projektor Management
Cable lock slot
Yes
Cable lock slot type
Kensington
Cables included
AC
Card reader integrated
No
Colour light output
3500 ANSI lumens
Compatible operating systems
Linux, Mac OS 10.10.x, Mac OS 10.7.x, Mac OS 10.8.x, Mac OS 10.9.x, Ubuntu 14.10, Ubuntu 15.04, Ubuntu 15.10, Ubuntu 16.04 LTS, Windows 10, Windows 8, Windows 8.1
Component video (YPbPr/YCbCr) in
0
Composite video in
1
Contrast ratio (dynamic)
14000:1
Contrast ratio (typical)
14000:1
Country of origin
Philippines
Depth
400 mm
DVI port
No
Ethernet LAN
Yes
Ethernet LAN (RJ-45) ports
1
Fixed focal length
3.7 mm
Focal length range
3.7 mm
Focus
Manual
Full HD
No
Harmonized System (HS) code
85286200
HDMI ports quantity
3
Headphone outputs
1
Height
149 mm
Interactive
Yes
Interactive input supported
Interactive pen
Keystone correction, horizontal
-3 - 3°
Keystone correction, vertical
-3 - 3°
Lamp power
250 W
LED indicators
Yes
Light source type
Lamp
Manual
Yes
Market positioning
Ulta short throw
Matrix size
1.5 cm (0.59")
Microphone in
Yes
Native aspect ratio
16:10
Noise level
35 dB
Noise level (economic mode)
30 dB
Number of colours
1.07 billion colours
Operating relative humidity (H-H)
20 - 80%
Operating temperature (T-T)
5 - 35 °C
Package depth
730 mm
Package height
335 mm
Package weight
20 kg
Package width
490 mm
Pallet gross height
15 cm
Pallet gross length
120 cm
Pallet gross weight
0 g
Pallet gross width
80 cm
Pallet height (UK)
15 cm
Pallet length (UK)
120 cm
Pallet weight (UK)
0 g
Pallet width (UK)
100 cm
Password protection
Yes
Placement
Wall
Power consumption (economy mode)
310 W
Power consumption (standby)
0.39 W
Power consumption (typical)
354 W
Power source
AC
Product colour
White, Grey
Product type
Ultra short throw projector
Products per pallet
12 pc(s)
Products per pallet (UK)
12 pc(s)
Products per pallet layer
2 pc(s)
Products per pallet layer (UK)
2 pc(s)
Projection distance (tele)
0 - 0.6 m
Projection distance (wide)
0 - 0.4 m
Projection technology
3LCD
Projector brightness
3500 ANSI lumens
Projector brightness (economic mode)
2900 ANSI lumens
Projector native resolution
WXGA (1280x800)
Quantity per pack
1 pc(s)
Quick start guide
Yes
Remote control included
No
RMS rated power
16 W
RS-232 ports
1
RS-232C
Yes
S-Video inputs quantity
1
Screen size compatibility
1524 - 2540 mm (60 - 100")
Serial interface type
RS-232C
Service life of light source
5000 h
Service life of light source (economic mode)
10000 h
Software support
via: AMX, Crestron (Network), Control4
Storage relative humidity (H-H)
10 - 90%
Storage temperature (T-T)
-10 - 60 °C
Supported aspect ratios
16:10
Throw ratio
0.28 - 0.37:1
USB 2.0 ports quantity
3
USB display function
3 in 1: Image / Mouse / Sound
Vertical scan range
100 - 120 Hz
Vertical synchronization (max)
0.12 kHz
Vertical synchronization (min)
0.1 kHz
VGA (D-Sub) ports quantity
3
Video colour modes
Blackboard, Cinema, Dynamic, Presentation, sRGB, Whiteboard
Video processing
10 bit
Weight
5.9 kg
White light output
3500 ANSI lumens
Width
367 mm
Windows operating systems supported
Windows 10, Windows 8, Windows 8.1
WLAN adapter included
Yes
Zoom ratio
1.35:1
Zoom type
Auto

Leaflet

Open Leaflet
Price history over the last 6 months
Epson EB-685Wi Ultra short throw projector 3500 ANSI lumens 3LCD WXGA (1280x800) White, Grey
Current
R44,743
Lowest
R36,175
Highest
R49,263
Change 24H
-R737   -2%
Week
+R2,069   +5%
Month
+R1,812   +4%
