EMITER EM/AH6509 19 inch 9U Wall-Mount Split Cabinet with Tempered Glass Door, 600x550x500 mm, Black

When floor space is scarce, the EMITER EM/AH6509 split hanging cabinet steps in with a space-saving wall-mounted design that doesn't compromise on security or visibility. Its 9U capacity accommodates standard 19-inch equipment, while the tempered glass front door with lock allows quick visual checks without exposing gear to unauthorized access. The solid steel side panels are removable and lockable, simplifying installation and maintenance. Finished in durable black RAL 9005 powder coating, this cabinet blends into any professional environment.

Highlights

• 9U rack capacity with standard 19" mounting rails
• Tempered glass front door with lock for secure access
• Removable solid steel side panels with locks
• Wall-mountable design saves valuable floor space
• 60 kg load capacity supports a wide range of equipment
• Top and bottom cable entry with brush strips for clean cable management
• Reversible door for left or right opening flexibility
• Passive ventilation with provision for optional fan unit

In daily use

The EM/AH6509 is engineered for straightforward installation and reliable operation. The welded frame of SPCC cold-rolled steel provides a sturdy foundation, while the removable side panels allow easy access during setup and maintenance. The tempered glass door not only protects equipment from dust and unauthorized access but also enables quick visual monitoring of indicator lights. The included cage nuts, screws, and mounting hardware simplify equipment installation, and the brush strips at cable entry points help maintain a tidy, organized rack.

Full specifications

• Rack Standard: 19 inch
• Rack Units: 9U
• Cabinet Type: Wall Mount Data Cabinet
• External Dimensions (W x D x H): 600 x 550 x 500 mm
• Front Door Type: Tempered Glass with Lock
• Side Panels: Removable Solid Steel with Locks
• Material: SPCC Cold Rolled Steel
• Construction: Welded Frame
• Load Capacity: 60 kg
• IP Rating: IP20
• Cable Entry: Top and Bottom with Brush Strips
• Ventilation: Passive, with provision for optional fan unit
• Color: Black (RAL 9005)
• Mounting: Wall Mountable
• Door Reversibility: Yes (left or right opening)
• Included Accessories: 2 Keys, Mounting Hardware, Cage Nuts & Screws (20 sets)
• Compliance: RoHS, CE

Final note

Compact, secure, and built to last, the EM/AH6509 is a smart choice for network installations where every square meter counts.
