DIGITUS CAT 8.1 S-FTP Patch Cable, Cu, LSZH, 0.5 m, Grey

The DIGITUS CAT 8.1 S-FTP Patch Cable is a high-performance network cable designed for demanding data center and enterprise environments. With pure copper conductors and LSZH jacket, it ensures reliable, fast, and safe data transmission.

Advantages

Supports data rates up to 40 Gbps and bandwidth up to 2000 MHz, making it ideal for 40GBASE-T applications. The S-FTP shielding (PiMF) provides excellent protection against electromagnetic interference. LSZH jacket reduces toxic smoke in case of fire, enhancing safety.

Suitable for

• Data centers requiring high-speed connections
• Enterprise networks with high bandwidth demands
• Server rooms where safety and performance are critical
• PoE applications including PoE, PoE+, and 4PPoE (PoE++)

Key specifications

• Cable Category: CAT 8.1
• Shielding: S-FTP (PiMF)
• Conductor: Pure Copper (Cu), AWG 26/7 stranded
• Jacket: LSZH (Low Smoke Zero Halogen)
• Length: 0.5 m
• Colour: Grey
• Connectors: RJ45 Male to RJ45 Male, gold-plated (50µm)
• Bandwidth: 2000 MHz
• Data Transfer Rate: 40 Gbps
• Wiring Standard: TIA/EIA 568B
• Outer Diameter: Approx. 6.2 mm
• PoE Support: PoE, PoE+, 4PPoE (PoE++)
• Operating Temperature: -20°C to +60°C
• Certifications: RoHS, REACH, CPR (Dca)

Recommendations

For optimal performance, pair this cable with CAT 8.1 compatible switches and network cards. Ensure proper installation to maintain shielding integrity.
