DC/DC Converter ATTE ASDIC-60-121-OF

The ATTE ASDIC-60-121-OF is a high-performance DC/DC converter designed for industrial applications requiring reliable power conversion. With a 24 VDC nominal input and 12 VDC output at 5 A, it delivers 60 W of power in a compact 1/4 brick package. This converter features wide input voltage range, high efficiency, and comprehensive protection features, making it ideal for demanding environments.

Advantages

High efficiency of 88% reduces energy loss and heat generation. Wide input voltage range (18-36 VDC) ensures stable operation even with fluctuating power sources. Remote ON/OFF control allows for flexible system management. Compact 1/4 brick form factor saves space in tight installations.

Suitable for

• Industrial automation systems
• Telecommunications equipment
• Distributed power architectures
• Embedded systems requiring isolated DC/DC conversion

Key specifications

• Input Voltage: 18-36 VDC (nominal 24 VDC)
• Output Voltage: 12 VDC
• Output Current: 5 A
• Output Power: 60 W
• Isolation Voltage: 1500 VDC
• Efficiency: 88% (Typ.)
• Operating Temperature: -40°C to +85°C
• Protection: OCP, OVP, SCP, UVLO
• Control: Remote ON/OFF
• Package: 1/4 Brick

Recommendations

For optimal performance, ensure adequate ventilation for natural convection cooling. This converter is suitable for use in systems requiring reliable isolated power conversion with a 2:1 input voltage ratio.
