Coaxial Connector F-type Televes ERD11N

The Televes ERD11N is a compact F-type coaxial connector designed for reliable signal transmission between coaxial cables and equipment. Featuring two F-type female interfaces in a single inline unit, this connector provides a straightforward connection point for TV, satellite, and RF installations. The unit is intended to ensure stable electrical contact and consistent impedance for typical home and professional coaxial setups.

Advantages

The connector offers a simple inline design that helps maintain signal integrity and reduces the risk of intermittent contact. Its dual F-type interfaces make it compatible with a wide range of coaxial leads and devices, enabling quick installations and repairs. The housing is built to withstand standard handling during installation and to keep connections secure over time.

Suitable for

• Connecting two coaxial cables in TV and satellite reception systems
• Extending cable runs or joining pre-terminated leads
• Temporary or permanent repairs of damaged coaxial connections
• Use in consumer and small professional RF distribution setups

Key specifications

• Connector type: F-type inline connector with two female F interfaces
• Application: RF, TV, satellite and general coaxial signal transmission
• Housing: compact inline form factor suitable for cable joints
• Compatibility: standard 75 Ω coaxial cables and F-type terminated leads

How to use

To use the connector, align and screw the male F-type ends of the coaxial cables into each of the connector's female interfaces until hand-tight, ensuring the center conductors make firm contact and the connectors sit flush. Avoid over-tightening with pliers to prevent damage to threads or cable jackets. After connection, verify signal quality on the target device and, if necessary, re-seat the connector to correct any intermittent contact.

Recommendations

For best results, use the connector with properly prepared coaxial cables with intact center conductors and correct F-type terminations. In fixed installations, support the cable near the connector to relieve mechanical strain. For outdoor or high-moisture environments, consider additional sealing or weatherproofing measures to protect the connection.
