Coaxial connector DELOCK 91764 — female BNC-style adapter

DELOCK 91764 is a female BNC-style coaxial adapter designed to connect RG-174 and RG-316 coaxial cables in radio frequency and signal transmission applications. The compact silver adapter provides a 50 Ω connection and includes a matching shrink tube for reliable electrical and mechanical joining of cable ends.

Advantages

The adapter supports standard 50 Ω impedance for minimal signal reflection and stable RF performance. Its BNC-style female form factor offers a familiar mating interface for many coaxial devices and test equipment. The package includes a shrink tube to protect and secure the cable connection while maintaining a compact footprint.

Suitable for

Key specifications

How to use

Strip the RG-174 and RG-316 cables according to the connector's preparation dimensions, insert the conductors into the adapter and secure them per the manufacturer's assembly method. Slide the supplied shrink tube over the joint and apply heat evenly until it shrinks and seals the connection. Ensure proper seating of the BNC-style female interface with the mating male plug to maintain electrical continuity.

Recommendations

Use in equipment and cabling systems rated for 50 Ω to avoid impedance mismatch. Inspect cable terminations and shrink tubing after installation to confirm a secure mechanical and electrical connection. For outdoor or high-vibration environments consider additional strain relief or sealing.
