Brumberg 87114080 Electrical Connector, 3-Pole, Push-In, 16A 250V, IP20, Black

The Brumberg 87114080 is a robust 3-pole electrical connector engineered for efficient power distribution in lighting and general electrical installations. Featuring tool-free push-in terminals, it accepts solid and stranded conductors from 0.5 to 2.5 mm², ensuring fast, secure, and low-resistance connections every time.

Overview

This free-hanging connector from Brumberg operates at 250 V AC with a rated current of 16 A, making it a reliable choice for luminaires, junction boxes, and control gear. The straight cable entry simplifies routing, while the compact black polyamide (PA) housing provides durability and safe handling in demanding environments.

What stands out

• Screwless push-in terminals slash installation time and remove the need for specialized tools.
• Wide operating temperature range from -25°C to +70°C suits both indoor and sheltered outdoor applications.
• The 3-pole design accommodates live, neutral, and earth connections within a single compact unit, saving space and reducing wiring complexity.
• IP20 protection rating guards against solid objects larger than 12 mm, suitable for interior environments.

Technical details

• Connector type: Plug connector with straight cable entry
• Number of poles: 3
• Rated voltage: 250 V AC
• Rated current: 16 A
• Connection method: Screwless (push-in terminal)
• Conductor cross-section (solid/stranded): 0.5 - 2.5 mm²
• Protection class: IP20
• Housing material: Polyamide (PA)
• Operating temperature: -25°C to +70°C
• Mounting type: Free hanging

Our verdict

A dependable, no-nonsense connector that combines quick-wire technology with a compact, practical form factor. The Brumberg 87114080 is a solid choice for electricians and lighting professionals who value efficiency, reliability, and consistent performance.
