DELOCK Panel Mount IEC C14 to F-Type Female Adapter Black 91195

Panel-mount adapter combining an IEC C14 male input with an F-type female output, enabling secure integration of power and RF signal connections through a single cut-out. Its screw-mounting design and compact panel cut-out dimensions make it ideal for custom enclosures and equipment panels.

Advantages

The adapter features a durable plastic housing in black, with a 75 Ohm impedance for reliable RF signal transmission. The IEC C14 connector supports up to 250 V and 10 A, while the F-type connector ensures stable coaxial connections. Panel mounting with 36 mm hole distance provides a firm, professional installation.

Suitable for

• Custom electronics enclosures requiring combined power and RF access
• Audio/video distribution panels and wall plates
• Test and measurement equipment with panel cut-outs
• Industrial control cabinets needing modular connectivity

Key specifications

• Connector 1: IEC C14 male (power input)
• Connector 2: F-type female (coaxial output)
• Panel cut-out: 28 x 20 mm
• Mounting hole distance: 36 mm
• Housing material: plastic, black
• Impedance: 75 Ohm (F-type)
• Voltage/current rating: 250 V / 10 A (IEC C14)
• Operating temperature: -10 °C to 60 °C
• Mounting method: screw mounting

Recommendations

For installations where space is limited but both power and RF connectivity are required, this adapter offers a streamlined solution. Verify panel thickness and cut-out dimensions before ordering to ensure a perfect fit.
