BRADY PermaSleeve Heat-Shrink Tubing, 3:1, White, 18-12 AWG, 0.187 in Dia, 1.5 in L, 100/Roll

Heat-shrink sleeves engineered for permanent, high-legibility wire and cable identification in demanding environments. The B-342 polyolefin material delivers a 3:1 shrink ratio, conforming tightly to irregular surfaces for crisp, smudge-proof legends that withstand abrasion, chemicals, and UV exposure.

Advantages

These sleeves provide a secure, non-adhesive grip once shrunk, eliminating flagging and peeling. The matte white finish ensures excellent contrast for thermal transfer printing, while the material's resistance to oils, solvents, and humidity guarantees long-term readability in industrial settings. The 3:1 ratio accommodates a wide range of wire diameters, reducing inventory needs.

Suitable for

• Wire and cable marking in control panels and machinery
• Electrical labeling for maintenance and repair
• Panel identification in harsh environments
• Applications requiring UL, CSA, and RoHS compliance

Key specifications

• Material: B-342 PermaSleeve Heat-Shrink Polyolefin
• Colour: White
• Shrink ratio: 3:1
• Expanded diameter: 0.187 in (4.75 mm)
• Shrunk diameter: 0.062 in (1.57 mm)
• Marker length: 1.5 in (38.1 mm)
• Wire gauge range: 18 AWG to 12 AWG
• Quantity: 100 sleeves per roll
• Operating temperature: -55°C to 135°C
• Compatible printers: BMP21-PLUS, BMP21-LAB, IDPAL, LABPAL

Recommendations

For optimal print quality, pair with Brady R4300, R4500, R6000, R6000HF, or R7961 thermal transfer ribbons. Store in a cool, dry place away from direct sunlight to preserve material integrity.
