BLEBOX Door Control Module doorBox PRO - GSM Access Controller with 2 Relays, 1000 Users, SMS & USB Programming

The BLEBOX doorBox PRO is a professional GSM-based access control module designed for remote door management. It enables authorized entry via phone call, SMS commands, or integration with Elmes remote controls. With support for up to 1000 users and 1000 event logs, it is ideal for residential buildings, offices, and small commercial facilities.

Advantages

Quad-band GSM ensures reliable operation across global networks. Two configurable relay outputs (NO/NC) allow control of doors, gates, or barriers. The module supports time schedules for outputs and user access, enhancing security and flexibility. Remote firmware updates via USB keep the system up to date.

Suitable for

• Access control for apartment buildings and gated communities
• Office entrance management
• Remote gate and barrier control
• Integration with existing intercom systems

Key specifications

• Communication Technology: GSM (Quad-band 850/900/1800/1900 MHz)
• Max. Number of Users: 1000
• Number of Relay Outputs: 2 (NO/NC, configurable)
• Relay Contact Rating: 1A/30V DC, 0.5A/125V AC
• Number of Digital Inputs: 2 (configurable)
• Power Supply: 10-15V DC
• Current Consumption (Max): 150 mA
• Programming Interface: USB (PC software), SMS commands
• Event Log Capacity: 1000 events
• Time Schedules: Yes (for outputs and user access)
• Caller ID Recognition: Yes
• Remote Control Support: Yes (Elmes UMB/DW200HT, up to 200 remotes)
• SIM Card Type: Mini-SIM (2FF)
• Antenna Connector: SMA Female
• Operating Temperature: -20°C to +55°C
• Housing Material: Plastic
• Mounting Type: Surface Mount
• Output Modes: Monostable, Bistable, Timed (1-999s)
• Firmware Update: Via USB

Recommendations

For optimal performance, use a reliable GSM network provider and ensure proper antenna placement. The doorBox PRO is compatible with standard electric door strikes and magnetic locks. For advanced configurations, utilize the PC software via USB.
