ATEN DVI HDBaseT KVM Extender with ExtremeUSB® (1920 x 1200 @ 100m)

ATEN DVI HDBaseT KVM Extender with ExtremeUSB® (1920 x 1200 @ 100m)
ATEN DVI HDBaseT KVM Extender with ExtremeUSB® (1920 x 1200 @ 100m)
ATEN DVI HDBaseT KVM Extender with ExtremeUSB® (1920 x 1200 @ 100m)
ATEN DVI HDBaseT KVM Extender with ExtremeUSB® (1920 x 1200 @ 100m)
ATEN DVI HDBaseT KVM Extender with ExtremeUSB® (1920 x 1200 @ 100m)
ATEN DVI HDBaseT KVM Extender with ExtremeUSB® (1920 x 1200 @ 100m)
R19,094
The CE610A USB DVI KVM Extender is a DVI and USB Extender that supports ExtremeUSB ® and HDBaseT technology. The CE610A can extend DVI and USB 2.0 signals up to 300 ft (100 m) from the source using a single Cat 5e/6 cable.1x CE610AL DVI HDBaseT KVM Extender with ExtremeUSB ® (Local Unit)1x CE610AR D... Read More
Stock 4 Code 1506192 Brand ATEN Model CE610A-AT-G Warranty 2 Years

Shipping & Returns

Estimated delivery Thursday, October 22
You will be kept updated through our detailed tracking system
Payment options
EFTPayFastBank CardSnapScanZapperGoogle PayApple PayMobicredMoreTymePay on Arrival
The CE610A USB DVI KVM Extender is a DVI and USB Extender that supports ExtremeUSB ® and HDBaseT technology. The CE610A can extend DVI and USB 2.0 signals up to 300 ft (100 m) from the source using a single Cat 5e/6 cable.
1x CE610AL DVI HDBaseT KVM Extender with ExtremeUSB ® (Local Unit)
1x CE610AR DVI HDBaseT KVM Extender with ExtremeUSB ® (Remote Unit)
1x LIN5-26W1-W11G Custom DVI Cable
1x LIN6-04U1-V1BG USB Cable
2x 0AD9-1B05-30EG Power Adapters
1x Mounting Kit
1x User Instructions

ATEN DVI HDBaseT KVM Extender with ExtremeUSB® (1920 x 1200 @ 100m). Type: Transmitter & receiver, Connectivity technology: Wired, Maximum transfer distance: 100 m. Transmitter video port type: DVI-D, Transmitter local keyboard/mouse port type: USB. Receiver local video port type: DVI-D. Transmitter width: 11.8 cm, Transmitter depth: 18.2 cm, Transmitter height: 2.87 cm. Package width: 98 mm, Package depth: 325 mm, Package height: 210 mm

Key Highlights
  • Uses a single Cat 5e cable to connect the local and remote units
  • Allows access to a computer or KVM installation from a remote console
  • Superior Video Quality – up to 1920 x 1200 @ 60 Hz at 100 m
  • Anti-jamming – resists signal interference during high-quality video transmissions using HDBaseT technology
  • ExtremeUSB ® – supports transparent USB 2.0 signals and true plug-and-play (no software or drivers required)
  • Supports USB 1.1 web cameras
  • USB 2.0 Support* – connects devices such as keyboard, mouse, audio, flash drive, printer, touch panel and other USB devices which require moderate amounts of bandwidth
  • Extends local PC Video/Keyboard/Mouse to remote side
  • Built-in 8KV/15KV ESD protection (Contact voltage 8KV; Air voltage 15KV)
  • Works with all major operating systems: Windows®, OS X®, and Linux®
  • Transmitter & receiver
  • Wired Maximum transfer distance: 100 m
  • Maximum analog resolution: 1920 x 1200 pixels
  • Transmitter video port type: DVI-D Transmitter local keyboard/mouse port type: USB
  • Receiver local video port type: DVI-D
Specifications
AC adapter included
Yes
Cable types supported
Cat5e
Cables included
USB
Connectivity technology
Wired
Firmware upgradeable
Yes
Harmonized System (HS) code
84733080
LED indicators
Link, Power, USB, Video
Manual
Yes
Master (outer) case gross weight
11.9 kg
Master (outer) case height
232 mm
Master (outer) case length
512 mm
Master (outer) case net weight
10.2 kg
Master (outer) case width
342 mm
Maximum analog resolution
1920 x 1200 pixels
Maximum resolution
1920 x 1200 pixels
Maximum transfer distance
100 m
Operating relative humidity (H-H)
0 - 80%
Operating temperature (T-T)
0 - 40 °C
Package depth
325 mm
Package height
210 mm
Package weight
2.1 kg
Package width
98 mm
Products per master (outer) case
5 pc(s)
Receiver depth
18.2 cm
Receiver height
2.87 cm
Receiver local video port type
DVI-D
Receiver weight
620 g
Receiver width
11.8 cm
RJ-45 ports quantity (receiver)
1
RJ-45 ports quantity (transmitter)
1
Storage temperature (T-T)
-20 - 60 °C
Transmitter depth
18.2 cm
Transmitter height
2.87 cm
Transmitter local keyboard/mouse port type
USB
Transmitter video port type
DVI-D
Transmitter weight
620 g
Transmitter width
11.8 cm
Type
Transmitter & receiver
USB 2.0 ports quantity
3
Weight
2.05 kg

Manual

Open Manual

Leaflet

Open Leaflet

Manual

Open Manual

Document

Open Document

Document

Open Document
