ARCTIC TP-4 Thermal Pad 4-Pack 120x20x0.5mm Grey

The ARCTIC TP-4 Thermal Pad is a high-quality, silicone-based thermal interface material designed for efficient heat transfer between components and heatsinks. This pack contains four pads, each measuring 120x20x0.5mm, providing a convenient solution for multiple applications or larger surfaces. With a thermal conductivity of 3.2 W/mK, these pads offer reliable thermal management for CPUs, GPUs, VRMs, SSDs, and chipsets.

Advantages

Non-adhesive yet naturally tacky, the TP-4 pads are easy to position and reposition without leaving residue. They are reusable, non-corrosive, and electrically non-conductive, ensuring safe use around sensitive electronics. The pads are compliant with RoHS standards and can withstand continuous temperatures from -40 to 200 °C.

Suitable for

• CPU and GPU cooling
• VRM and chipset heat dissipation
• SSD thermal management
• Any application requiring a 0.5mm thick thermal pad

Key specifications

• Thermal Conductivity: 3.2 W/mK
• Dimensions: 120 x 20 x 0.5 mm (per pad)
• Quantity: 4 pads per pack
• Colour: Grey
• Material: Silicone-based
• Density: 2.3 g/cm³
• Hardness: 35 Shore 00
• Continuous Use Temperature: -40 to 200 °C
• Breakdown Voltage: 4.5 kV/mm
• Volume Resistivity: 1 x 10^12 Ω·cm
• Electrical Conductivity: No
• Corrosive: No
• Reusable: Yes
• Adhesive Properties: Non-adhesive (naturally tacky)
• Compliance: RoHS

Recommendations

For optimal thermal performance, ensure surfaces are clean and dry before application. The pads can be cut to size if needed. Store in a cool, dry place.
