ALLNET ALL-BRICK-0560 PoE Load Resistor 560 mA

The ALLNET ALL-BRICK-0560 is a PoE load resistor (dummy load) designed to simulate a Powered Device (PD) for testing Power over Ethernet (PoE) switches, injectors, and midspans. It draws a fixed current of 560 mA, making it ideal for verifying PoE power delivery and troubleshooting network installations.

Advantages

This compact and robust tester allows you to quickly confirm that your PoE equipment is delivering the correct power. With an LED indicator for PoE status, you can easily see when power is being supplied. Its plastic housing is durable and lightweight, suitable for field use.

Suitable for

• Testing PoE switches, injectors, and midspans
• Verifying PoE power delivery in network installations
• Troubleshooting PoE connectivity issues
• Network technicians and installers

Key specifications

• Product Type: PoE Load Resistor / Dummy Load
• Simulated Current Draw: 560 mA
• PoE Standard Compatibility: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
• Connector Type: RJ45 Male
• LED Indicator: Yes (for PoE status)
• Input Voltage Range: 48 - 57 V DC
• Simulated Power (at 48V): Approx. 26.88 W
• Simulated Power (at 57V): Approx. 31.92 W
• Housing Material: Plastic
• Color: Black
• Application: Testing PoE switches, injectors, and midspans
• Load Type: Fixed
• Power Delivery Method: Power over Ethernet (PoE)
• Number of Pairs for Power: 4-pair (for 802.3bt compatibility)

Recommendations

For comprehensive network testing, consider pairing this PoE load resistor with a network cable tester or PoE tester. Always ensure your PoE source is compatible with the load specifications.
