ALLNET ALL-BRICK-0551 50 Ohm BNC Male Termination Resistor

The ALLNET ALL-BRICK-0551 is a high-quality 50 Ohm BNC male termination resistor designed for coaxial cable systems, RF networks, and test & measurement applications. It ensures signal integrity by preventing reflections and maintaining proper impedance matching.

Advantages

This termination resistor offers reliable performance with a frequency range from DC to 1 GHz and a low VSWR of less than 1.3:1. Its nickel-plated brass body and gold-plated brass contacts provide excellent durability and corrosion resistance. The PTFE insulator ensures stable electrical characteristics over a wide temperature range.

Suitable for

• Coaxial cable systems requiring 50 Ohm termination
• RF network impedance matching
• Test and measurement setups
• Broadcast and communication equipment

Key specifications

• Resistance: 50 Ohm
• Connector: BNC Male
• Power Rating: 0.5 W
• Frequency Range: DC - 1 GHz
• VSWR: < 1.3:1
• Operating Temperature: -55°C to +85°C
• Voltage Rating: 500 V peak
• Body Material: Nickel-plated Brass
• Contact Material: Gold-plated Brass
• Insulator Material: PTFE
• Resistance Tolerance: ±5%
• Colour: Silver
• RoHS Compliant

Recommendations

For optimal performance, use this termination resistor in 50 Ohm systems. Ensure proper installation by securely connecting the BNC male connector to a female BNC port. Avoid exceeding the specified power and voltage ratings.
