ALLNET ALL-BRICK-0515 5.15 Ohm 10W Wirewound Ceramic Power Resistor

The ALLNET ALL-BRICK-0515 is a high-quality wirewound ceramic power resistor designed for demanding applications requiring precise resistance and high power handling. With a resistance value of 5.15 Ohm and a power rating of 10W, this through-hole resistor offers reliable performance in a compact brick-style ceramic package. Its robust construction ensures excellent heat dissipation and long-term stability, making it ideal for power supplies, industrial controls, and test equipment.

Advantages

This resistor provides exceptional durability and accuracy. The wirewound element delivers low inductance and high surge capability, while the ceramic housing offers superior thermal conductivity and flame retardancy. The ±5% tolerance ensures consistent performance, and the wide operating temperature range from -55°C to +155°C allows use in harsh environments.

Suitable for

• Power supply circuits
• Industrial control systems
• Test and measurement equipment
• Automotive electronics
• Audio amplifiers

Key specifications

• Resistance: 5.15 Ohm
• Power Rating: 10 W
• Tolerance: ±5%
• Type: Wirewound
• Mounting: Through-hole
• Terminals: 2
• Temperature Coefficient: ±200 ppm/°C
• Operating Temperature: -55°C to +155°C
• Package: Ceramic Power Resistor (Brick-style)
• Series: ALL-BRICK
• Housing Material: Ceramic
• Element Material: Resistance Wire
• Rated Voltage: 7.17 V
• Dielectric Strength: 500 V AC
• Lead Material: Tinned Copper
• Flame Retardant: Yes
• Compliance: RoHS Compliant

Recommendations

For optimal performance, ensure proper heat sinking when operating near maximum power. This resistor is a direct replacement for many standard brick-style power resistors. Always verify compatibility with your circuit requirements.
