ALLNET ALL-BRICK-0508 PoE to 5V 2A Power Supply Adapter, Black

The ALLNET ALL-BRICK-0508 is a compact and reliable PoE (Power over Ethernet) to 5V DC power adapter, designed to provide a convenient power solution for low-power devices such as IP cameras, wireless access points, and other network equipment. It converts IEEE 802.3af PoE input (48V) to a stable 5V DC output at 2A (10W), eliminating the need for a separate power outlet near the device. The unit features a sleek black plastic housing with LED power indicator, and includes both data and power output ports for seamless integration.

Advantages

Simplifies installation by combining power and data over a single Ethernet cable, reducing cable clutter and the need for additional power outlets. Ideal for locations where power access is limited or difficult to reach. The built-in overload and short circuit protection ensures safe operation of connected devices.

Suitable for

• IP cameras requiring 5V DC power
• Wireless access points and routers
• Network switches and other low-power 5V devices
• IoT devices and smart home sensors

Key specifications

• PoE Standard: IEEE 802.3af
• Input Voltage: 48V DC (from PoE)
• Output Voltage: 5V DC
• Output Current: 2A
• Output Power: 10W
• Data Transfer Rate: 10/100 Mbps (Fast Ethernet)
• PoE Input Port: 1x RJ45
• Data Output Port: 1x RJ45
• Power Output Port: 1x DC Jack (5.5mm outer / 2.1mm inner)
• DC Cable Length: Approx. 15 cm
• LED Indicators: Power
• Operating Temperature: 0°C to 40°C
• Storage Temperature: -20°C to 70°C
• Operating Humidity: 10% to 90% (non-condensing)
• Housing Material: Plastic
• Color: Black
• Protection Features: Overload, Short Circuit

Recommendations

For optimal performance, use with IEEE 802.3af compliant PoE switches or injectors. Ensure the connected device does not exceed 10W total power consumption. The adapter is not suitable for outdoor use without additional weatherproofing.
