ALLNET ALL-BRICK-0486 Resistor 4.7 kOhm 0.25W Metal Film Axial

The ALLNET ALL-BRICK-0486 is a high-quality metal film resistor with a resistance of 4.7 kOhm and a power rating of 0.25W. Designed for through-hole mounting with axial leads, this resistor offers excellent stability and low noise, making it ideal for a wide range of electronic applications. The resistor features a 5-band color code (Yellow, Violet, Black, Red, Brown) and is RoHS compliant.

Advantages

This resistor provides precise resistance with ±1% tolerance and a low temperature coefficient of ±50 ppm/°C, ensuring reliable performance across a broad temperature range from -55°C to +155°C. Its metal film construction guarantees low noise and high stability, while the tinned copper leads ensure easy soldering and long-term durability.

Suitable for

• General purpose electronics
• Prototyping and hobby projects
• Repair and maintenance of electronic devices
• Educational kits and experiments

Key specifications

• Resistance: 4.7 kOhm
• Tolerance: ±1%
• Power Rating: 0.25W (1/4W)
• Type: Metal Film
• Mounting: Through-hole (Axial)
• Number of Terminals: 2
• Temperature Coefficient: ±50 ppm/°C
• Operating Temperature Range: -55°C to +155°C
• Max Working Voltage: 200V
• Max Overload Voltage: 400V
• Dielectric Withstanding Voltage: 500V
• Body Length: 6.3 mm
• Body Diameter: 2.5 mm
• Lead Diameter: 0.5 mm
• Lead Material: Tinned Copper
• Color Code: Yellow, Violet, Black, Red, Brown
• Noise Level: Low Noise
• Series: ALL-BRICK
• Packaging: Bulk
• RoHS Compliant: Yes

Recommendations

For best results, use this resistor in low-power circuits where precision and stability are required. Ensure proper heat dissipation and avoid exceeding the maximum voltage ratings.
