AJA OG-ROI-SDI 3G-SDI Region of Interest Converter Card

The AJA OG-ROI-SDI is a high-performance openGear 3.0 compliant single-slot card designed for professional video production environments. It provides flexible region of interest (ROI) selection with pan and zoom, along with up/down/cross conversion and frame rate conversion. Ideal for broadcast, live event, and post-production workflows, this card ensures reliable 10-bit video processing and 16-channel embedded audio pass-through.

Advantages

• Flexible ROI selection with pan and zoom for precise framing
• Up/down/cross conversion and frame rate conversion with motion adaptive de-interlacing
• 10-bit full data path for high-quality video processing
• 16-channel embedded SDI audio pass-through
• Genlock to external reference for synchronized operation
• Controlled via openGear DashBoard over Ethernet

Suitable for

• Broadcast studios requiring flexible video conversion and ROI
• Live event production with multi-format SDI signals
• Post-production facilities needing reliable signal processing
• Integration into openGear frames for scalable solutions

Key specifications

• Input Video Interface: 1x 3G-SDI (BNC)
• Output Video Interface: 2x 3G-SDI (BNC)
• Reference Input: 1x BNC (Blackburst or Tri-level Sync)
• Max Input/Output Resolution: 1080p60
• Scaling: Up/Down/Cross Conversion
• Frame Rate Conversion: Yes, with motion adaptive de-interlacing
• Video Processing: 10-bit full data path
• Audio Support: 16-channel embedded SDI audio pass-through
• Control Interface: openGear DashBoard (via Ethernet)
• Form Factor: openGear 3.0 compliant, single-slot card
• Power Consumption: 10W typical
• Operating Temperature: 0 to 40°C

Recommendations

For optimal performance, install the OG-ROI-SDI in an openGear frame with adequate ventilation. Use high-quality BNC cables for SDI connections. Configure via DashBoard for precise ROI and conversion settings.
