ACO INS-ZS Standalone Combination Lock, Surface-Mounted, Zinc Alloy, 12V DC, IP44, 200 User Codes

The ACO INS-ZS is a standalone combination lock designed for secure access control in various environments. This surface-mounted lock features a durable zinc alloy housing and a backlit keypad for easy operation in low-light conditions. It supports up to 200 user codes with 4-8 digit lengths and offers both monostable and bistable operating modes. With IP44 protection rating, it is suitable for indoor and outdoor use. The lock includes tamper protection and master code support for enhanced security.

Advantages

Easy to install and program via keypad, no additional software required. The robust zinc alloy construction ensures long-lasting durability. The backlit keypad and tamper alarm provide convenience and security. Low power consumption with standby current of only 30 mA.

Suitable for

• Office doors
• Storage rooms
• Warehouses
• Residential gates
• Industrial facilities

Key specifications

• Product Type: Standalone Code Lock / Keypad
• Installation Type: Surface-Mounted
• Housing Material: Zinc Alloy
• Power Supply: 12V DC
• Current Consumption (Standby): 30 mA
• Current Consumption (Active): 100 mA
• Number of User Codes: 200
• Code Length: 4-8 Digits
• Relay Outputs: 1 (NO/NC)
• Operating Modes: Monostable, Bistable
• Protection Rating: IP44
• Operating Temperature: -25°C to +55°C
• Keypad Backlight: Yes
• Tamper Protection: Yes
• Master Code Support: Yes
• Programming Method: Keypad

Recommendations

For optimal performance, use a regulated 12V DC power supply. Ensure the mounting surface is flat and secure. Regularly test the lock and update user codes as needed.
