ABUS Security-Center Ecoline LS1020 PIR Motion Sensor, White, 12 m Range, 180° Angle, IP44, Wall Mount

For reliable motion detection in driveways, entrance areas, and commercial premises, the ABUS Security-Center Ecoline LS1020 delivers a robust passive infrared (PIR) sensor solution. This wall-mounted detector responds to moving heat sources, making it an effective security companion for both indoor and outdoor use. Whether you're safeguarding a private home or a business, the LS1020 offers dependable performance with a detection range of up to 12 metres and a wide 180° angle.

Key specifications

• Detection technology: Passive Infrared (PIR)
• Detection range: 12 metres
• Detection angle: 180°
• Power supply: 230 V AC, 50 Hz
• Max. switching capacity (resistive load): 1200 W
• Max. switching capacity (LED/fluorescent): 300 W
• Time setting range: 10 seconds – 15 minutes
• Light sensitivity range: 3 – 2000 lux
• Protection rating: IP44
• Operating temperature: -20°C to +40°C
• Mounting type: Wall-mounted
• Recommended mounting height: 1.8 – 2.5 metres
• Colour: White
• Material: UV-resistant plastic
• Output type: Relay (normally open)
• Standby power consumption: <0.5 W

Why choose it

The LS1020 combines high-quality ABUS engineering with a sleek, unobtrusive white housing. Its adjustable time and lux settings give you control over how the sensor behaves, while the IP44 rating ensures protection against splashing water, making it suitable for sheltered outdoor areas. The relay output is compatible with most alarm systems, buzzers, or light controls.

Ideal use cases

• Activating outdoor lighting when someone approaches
• Triggering an alarm when motion is detected in a protected zone
• Controlling ventilation or other devices based on presence
• Enhancing security for residential driveways and entrances
• Monitoring commercial premises after hours

Good to know

Installation is straightforward with the included mounting bracket. The sensor's adjustable settings allow fine-tuning to avoid false triggers from small animals or moving foliage. For best performance, mount at the recommended height and angle. The LS1020 is designed for continuous operation and has a low standby power consumption, contributing to energy efficiency.
