Zebra Übergabestation-Bausatz

In fast-paced retail, logistics, and field service environments, keeping mobile computers charged, synced, and ready is critical. This single-slot cradle kit from Zebra provides a reliable desktop solution for your TC51, TC52, TC56, or TC57 devices, ensuring they are always powered and connected to your back-end systems.

Who is it for

Enterprises that rely on Zebra mobile computers for inventory management, order picking, or customer service will find this cradle essential. It is ideal for workstations where a single device needs to be docked for charging and data transfer without the complexity of multi-slot cradles.

Main features

• Single-slot design for one Zebra TC5x series mobile computer
• Charges the device battery while docked
• USB 2.0 Type B port for data synchronization with a host PC
• DC power jack for external power supply (sold separately)
• LED indicators show charging status (red/green)
• Durable black ABS plastic housing for long-term use
• Desktop mounting for stable operation

Specifications

• Compatible devices: Zebra TC51, TC52, TC56, TC57
• Connectivity: USB 2.0 (Type B)
• Power input: DC jack (requires PWR-BGA12V50W0WW and CBL-DC-388A1-01, not included)
• LED indicators: Charging status (red/green)
• Material: High-grade ABS plastic
• Operating temperature: 0°C to 40°C (32°F to 104°F)
• Storage temperature: -20°C to 60°C (-4°F to 140°F)
• Humidity: 5% to 95% non-condensing
• Certifications: RoHS, CE, FCC, UL

Tips

To use this cradle, you will need a compatible power supply and DC cable (sold separately). For data sync, connect the cradle to your PC using a standard USB 2.0 cable. Place the cradle on a flat, stable surface near your workstation for easy access.
