WAGO 281-611 TOPJOB® S Through Terminal Block, 3 Connection Points, 6 mm², Gray, DIN-35 Rail

The WAGO 281-611 is a high-quality through terminal block from the TOPJOB® S series, designed for reliable and maintenance-free electrical connections. With 3 connection points and CAGE CLAMP® technology, it ensures secure, vibration-proof wiring for solid and fine-stranded conductors up to 6 mm² (AWG 10). Rated for 800 V and 41 A, this gray terminal block is ideal for industrial control panels and junction boxes.

Advantages

Push-button actuation allows tool-free wiring, saving installation time. The compact design with 1 potential and 1 level optimizes space on DIN-35 rails. Polyamide insulation with UL94 V-0 flammability rating ensures high safety and durability in demanding environments.

Suitable for

• Industrial automation and control systems
• Building infrastructure and electrical distribution
• Machine building and panel wiring

Key specifications

• Connection Technology: CAGE CLAMP®
• Nominal Cross Section: 6 mm² (AWG 10)
• Solid Conductor Range: 0.25 - 10 mm² (22 - 8 AWG)
• Fine-Stranded Conductor Range: 0.25 - 6 mm² (22 - 10 AWG)
• Rated Voltage (EN): 800 V
• Rated Surge Voltage: 8 kV
• Rated Current (EN): 41 A
• Pollution Degree: 3
• Operating Temperature: -35 to +85 °C
• Mounting: DIN-35 Rail

Recommendations

For optimal performance, use with WAGO marking strips and end stops. Suitable for use in environments with high vibration or temperature fluctuations.
