WAGO 280-637 End Plate, Gray, 5 mm Width, TOPJOB® S Series

The WAGO 280-637 End Plate is a high-quality accessory designed for use with WAGO 280 Series terminal blocks. It provides insulation and visual separation between adjacent terminal blocks, ensuring safe and organized wiring in industrial and building installations. Manufactured from durable Polyamide 66 (PA 66) with a UL94 V-0 flammability rating, this end plate offers reliable performance in demanding environments.

Advantages

This end plate ensures clear physical and electrical separation between terminal block assemblies, reducing the risk of short circuits and improving maintenance accessibility. Its snap-on mounting allows for quick and tool-free installation, saving time during assembly. The gray color provides easy identification and blends with standard industrial equipment.

Suitable for

• Industrial control panels
• Building automation systems
• Distribution boards
• Any application using WAGO 280 Series terminal blocks

Key specifications

• Product Type: End Plate
• Series: TOPJOB® S
• Color: Gray
• Material: Polyamide 66 (PA 66)
• Flammability Rating: UL94 V-0
• Mounting Type: Snap-on
• Width: 5 mm
• Height from DIN-rail: 36.5 mm
• Depth: 50.5 mm
• Operating Temperature Range: -35 to +105 °C
• Pollution Degree: 3
• Nominal Voltage (IEC/EN 60947-7-1): 800 V
• Nominal Impulse Withstand Voltage: 8 kV
• Standards Compliance: IEC/EN 60947-7-1

Recommendations

For optimal performance, use this end plate with WAGO 280 Series terminal blocks. Ensure proper installation by snapping the plate securely onto the DIN-rail. Always follow local electrical codes and standards.
