WAGO 243-212 PUSH WIRE® Connector, 2-Conductor, 6 A, 250 V, Grey/Yellow, Polyamide

The WAGO 243-212 is a compact PUSH WIRE® connector from the 243 Series, designed for reliable and tool-free wiring of solid conductors. Ideal for lighting applications, this 2-conductor connector offers a rated current of 6 A and a rated voltage of 250 V, with a rated impulse voltage of 2.5 kV. The grey housing with yellow marking ensures easy identification, while the polyamide (PA 6.6) insulation provides excellent durability and a flammability rating of UL 94 V-2.

Advantages

Tool-free PUSH WIRE® connection technology saves installation time and ensures secure, maintenance-free connections. The compact design allows for high-density wiring in junction boxes and lighting fixtures. Operating temperature range from -35 °C to +105 °C makes it suitable for demanding environments.

Suitable for

• Lighting fixtures and luminaires
• Junction boxes and distribution boards
• Industrial control cabinets
• Building automation systems

Key specifications

• Product Type: PUSH WIRE® Connector
• Series: 243 Series (Lighting Connectors)
• Number of Conductors: 2
• Rated Current: 6 A
• Rated Voltage: 250 V
• Rated Impulse Voltage: 2.5 kV
• Connection Technology: PUSH WIRE®
• Connectable Conductor Size (Solid): 0.5 - 1.5 mm² (AWG 20 - 16)
• Strip Length: 9 - 11 mm
• Insulation Material: Polyamide (PA 6.6)
• Color: Grey
• Flammability Rating: UL 94 V-2
• Pollution Degree: 2
• Operating Temperature: -35 °C to +105 °C
• Standards/Approvals: EN 60998, UL 486C, CSA C22.2 No. 188

Recommendations

For optimal performance, use with solid copper conductors only. Ensure strip length is within 9-11 mm for proper insertion. Not suitable for stranded or fine-stranded conductors without ferrule.
