WAGO 210-133 2-Conductor CAGE CLAMP Terminal Block, 2.5 mm², Gray, DIN Rail Mount

The WAGO 210-133 is a high-quality 2-conductor terminal block featuring the innovative CAGE CLAMP® connection technology. Designed for reliable and maintenance-free wiring, this terminal block is ideal for a wide range of industrial and commercial applications. With a nominal cross-section of 2.5 mm² (12 AWG) and a rated voltage of 800 V, it ensures safe and efficient electrical connections.

Advantages

The CAGE CLAMP® connection technology provides a vibration-proof, gas-tight, and corrosion-resistant connection that saves time and reduces installation errors. The compact design allows for high-density wiring on DIN-35 rails, optimizing cabinet space. The transparent housing made of polyamide (PA) offers excellent insulation and flammability rating UL94 V0 for enhanced safety.

Suitable for

• Industrial control panels
• Building automation systems
• Power distribution units
• Lighting control systems
• Machine wiring

Key specifications

• Connection Technology: CAGE CLAMP®
• Number of Conductors: 2
• Number of Potentials: 1
• Nominal Cross-Section: 2.5 mm² (12 AWG)
• Solid Conductor Size: 0.08 - 2.5 mm² (28 - 12 AWG)
• Fine-Stranded Conductor Size: 0.08 - 2.5 mm² (28 - 12 AWG)
• Nominal Voltage (EN 60947-7-1): 800 V
• Nominal Current (EN 60947-7-1): 24 A
• Rated Impulse Voltage: 8 kV
• Pollution Degree: 3
• Insulating Material: Polyamide (PA)
• Color: Gray
• Mounting Type: DIN-35 Rail
• Stripping Length: 8 - 9 mm
• Operating Temperature: -35 to +105 °C
• Flammability Rating: UL94 V0
• Approvals: VDE, UL, CSA

Recommendations

For optimal performance, use with WAGO marking strips and accessories. Ensure proper stripping length and torque settings as per manufacturer guidelines.
