WAGO 2016-7607 TOPJOB S Through Terminal Block, 3-Conductor, 16 mm², Gray

The WAGO 2016-7607 is a high-quality through terminal block from the TOPJOB S series, designed for reliable and maintenance-free electrical connections. With a nominal cross section of 16 mm² (6 AWG) and Push-in CAGE CLAMP® connection technology, it ensures fast and secure wiring for solid and fine-stranded conductors. This 3-conductor terminal block is rated for 1000 V and 76 A, making it suitable for demanding industrial applications. Its compact dimensions (12 mm width, 85.7 mm height, 40.8 mm depth) allow for space-saving installation on DIN-rail 35. The gray polyamide housing provides excellent insulation and durability.

Advantages

Push-in CAGE CLAMP® technology enables tool-free, vibration-proof connections, reducing installation time. The terminal block is approved by VDE, UL, CSA, and EAC, ensuring compliance with international standards. Its wide operating temperature range (-35 to +105 °C) and pollution degree 3 rating guarantee reliable performance in harsh environments.

Suitable for

• Industrial control cabinets
• Building automation systems
• Power distribution panels
• Machine wiring

Key specifications

• Series: TOPJOB S
• Connection technology: Push-in CAGE CLAMP®
• Number of conductors: 3
• Nominal cross section: 16 mm² (6 AWG)
• Solid conductor range: 0.5 … 25 mm² (20 … 4 AWG)
• Fine-stranded conductor range: 0.5 … 16 mm² (20 … 6 AWG)
• Rated voltage (EN): 1000 V
• Rated current (EN): 76 A
• Rated surge voltage: 8 kV
• Stripped length: 20 … 22 mm (0.79 … 0.87 in)
• Mounting: DIN-rail 35
• Color: Gray
• Housing material: Polyamide (PA)
• Pollution degree: 3
• Operating temperature: -35 … +105 °C
• Approvals: VDE, UL, CSA, EAC

Recommendations

For optimal performance, ensure proper stripping length and use conductors within the specified cross-section range. This terminal block is ideal for new installations and retrofits in industrial environments.
