WAGO 2016-1207 TOPJOB® S 2-Conductor Through Terminal Block, 16 mm², 1000 V, Gray, DIN Rail Mount

The WAGO 2016-1207 is a high-quality 2-conductor through terminal block from the TOPJOB® S series, designed for reliable and maintenance-free wiring in industrial and building installations. With a nominal cross-section of 16 mm² (6 AWG) and a rated voltage of 1000 V, it is suitable for a wide range of applications. The push-in CAGE CLAMP® connection technology ensures fast and secure wiring without the need for tools.

Advantages

• Tool-free push-in connection for solid and stranded conductors
• Compact design saves space on DIN rail
• High rated voltage and current for demanding applications
• Vibration-proof and maintenance-free connections
• Clear marking and color coding for easy identification

Suitable for

• Industrial control cabinets
• Building automation systems
• Power distribution
• Machine building
• Railway and transportation

Key specifications

• Series: TOPJOB® S
• Connection technology: Push-in CAGE CLAMP®
• Number of conductors: 2
• Number of potentials: 1
• Nominal cross section: 16 mm² (6 AWG)
• Rated voltage (EN): 1000 V
• Rated current (EN): 76 A
• Rated impulse voltage: 8 kV
• Pollution degree: 3
• Mounting type: DIN-35 rail
• Color: Gray
• Insulating material: Polyamide (PA66)
• Solid conductor size: 0.5 … 25 mm² (20 … 4 AWG)
• Stranded conductor size: 0.5 … 16 mm² (20 … 6 AWG)
• Fine-stranded conductor size (with ferrule): 0.5 … 16 mm² (20 … 6 AWG)
• Strip length: 18 … 20 mm (0.71 … 0.79 inch)
• Wiring type: Front-entry
• Operating temperature: -35 °C to +85 °C
• Flammability rating: UL 94 V-0
• Approvals: VDE, UL, CSA, EAC, KEMA/KEUR

Recommendations

For optimal performance, use with WAGO marking strips and accessories. Ensure proper strip length and conductor preparation for reliable connections.
