WAGO 2007-8873 3-Phase Power Supply 480W 24V 20A DIN Rail

The WAGO 2007-8873 is a high-efficiency 3-phase power supply designed for industrial automation and control systems. With a rated power output of 480 W and an output voltage of 24 V DC at 20 A, it provides reliable and stable power for demanding applications. The unit features a wide input voltage range of 3 x 320-575 V AC or 450-800 V DC, making it suitable for global use. Its compact metal housing and DIN rail mounting simplify installation in control cabinets.

Advantages

This power supply offers exceptional efficiency of over 94%, reducing energy costs and heat generation. It includes comprehensive protection features such as overload and short-circuit protection, ensuring safe operation. The push-in CAGE CLAMP® connection technology enables fast and tool-free wiring, saving installation time. The DC OK LED provides clear status indication, and the unit supports parallel and series operation for increased flexibility.

Suitable for

• Industrial automation systems
• Control cabinets and switchgear
• Building automation and HVAC
• Process control and instrumentation
• Machine building and robotics

Key specifications

• Input Voltage (AC): 3 x 320-575 V AC
• Input Voltage (DC): 450-800 V DC
• Output Voltage: 24 V DC
• Output Current: 20 A
• Rated Power: 480 W
• Efficiency: >94%
• Mounting: DIN Rail
• Operating Temperature: -25 to +70 °C
• Protection Class: IP20
• Connection: Push-in CAGE CLAMP®
• Housing Material: Metal
• Cooling: Convection
• Approvals: UL 61010, GL, CE, RCM, EAC

Recommendations

For optimal performance, ensure adequate ventilation and do not exceed the rated output current. This power supply is ideal for use in industrial environments where reliability and efficiency are critical. Pair with WAGO DIN rail accessories for a complete solution.
