WAGO 2004-1207 TOPJOB® S Through Terminal Block, 6 mm², Gray, DIN-rail Mount

The WAGO 2004-1207 is a high-quality through terminal block from the TOPJOB® S series, designed for reliable and maintenance-free wiring in industrial and building installations. With a compact design of 6.2 mm width, it offers 3 connection points and 1 potential, supporting solid and fine-stranded conductors up to 10 mm² (AWG 8). The Push-in CAGE CLAMP® connection technology ensures fast, tool-free wiring, saving time and reducing installation errors.

Advantages

Push-in CAGE CLAMP® technology allows direct insertion of solid conductors without tools, while fine-stranded conductors can be connected using a simple operating tool. The terminal block is rated for 800 V (III/3) and 41 A, making it suitable for demanding applications. Its compact 6.2 mm width saves space on the DIN-rail, and the gray polyamide housing provides excellent insulation and flammability rating V0 per UL94.

Suitable for

• Industrial control cabinets
• Building automation systems
• Power distribution and signal wiring
• Applications requiring high reliability and vibration resistance

Key specifications

• Number of Potentials: 1
• Number of Connection Points: 3
• Number of Levels: 1
• Connection Technology: Push-in CAGE CLAMP®
• Nominal Cross Section: 6 mm² (AWG 10)
• Solid Conductor Size: 0.5 ... 10 mm² / 20 ... 8 AWG
• Fine-Stranded Conductor Size: 0.5 ... 6 mm² / 20 ... 10 AWG
• Nominal Voltage (III/3): 800 V
• Rated Surge Voltage (III/3): 8 kV
• Nominal Current: 41 A
• Color: Gray
• Mounting Type: DIN-rail 35
• Insulating Material: Polyamide (PA 66)
• Pollution Degree: 3
• Flammability Rating: V0 per UL94
• Operating Temperature: -35 ... +85 °C
• Stripping Length: 12 ... 14 mm / 0.47 ... 0.55 inch
• Wiring Type: Front-entry wiring
• Series: TOPJOB® S

Recommendations

For optimal performance, use WAGO operating tools and accessories. Ensure proper stripping length and conductor preparation for reliable connections. This terminal block is ideal for new installations and retrofitting existing systems.
