WAGO 2003-6641 End Plate for TOPJOB S 2003 Series, Grey, 5.2 mm Width

The WAGO 2003-6641 is a high-quality end plate designed for use with WAGO TOPJOB S 2003 Series terminal blocks. This grey polyamide (PA 66) end section provides reliable insulation and mechanical closure for the open side of terminal block assemblies, ensuring safe and organized wiring in industrial and commercial applications.

Advantages

• Provides secure insulation for terminal blocks up to 800 V (IEC) / 600 V (UL)
• Snap-on mounting for quick and easy installation without tools
• Made from self-extinguishing polyamide (PA 66) with UL 94 V-0 flammability rating
• Wide operating temperature range from -35 to +105 °C
• Compact 5.2 mm width saves space on DIN rails
• RoHS and REACH compliant, environmentally friendly

Suitable for

• Insulating and closing off the open side of WAGO TOPJOB S 2003 Series terminal block assemblies
• Industrial control panels, switchgear, and distribution boards
• Applications requiring reliable electrical insulation and mechanical protection

Key specifications

• Product Type: End Plate / End Section
• Series: WAGO TOPJOB S 2003
• Colour: Grey
• Material: Polyamide (PA 66)
• Flammability Rating: UL 94 V-0
• Width: 5.2 mm
• Height: 54.7 mm
• Depth: 110 mm
• Mounting: Snap-on
• Operating Temperature: -35 to +105 °C
• Approvals: UL, CSA, VDE, EAC, KEMA/KEUR, RINA, GL, LR, BV, DNV

Recommendations

For optimal performance and safety, always use genuine WAGO end plates with compatible TOPJOB S terminal blocks. Ensure proper installation according to manufacturer guidelines.
