WAGO 2002-482 End Plate, Grey, 61.2 mm Height, TOPJOB S Series

The WAGO 2002-482 is a high-quality end plate designed for use with WAGO 2002 Series terminal blocks. Part of the TOPJOB S series, this end plate provides reliable insulation and closure for terminal block assemblies, ensuring safety and organization in electrical installations. Made from durable Polyamide 66 (PA 66) with a UL 94 V-0 flammability rating, it offers excellent thermal and mechanical resistance. The grey color and snap-on mounting make installation quick and easy.

Advantages

This end plate ensures proper insulation and separation of terminal blocks, preventing accidental contact and short circuits. Its robust construction and halogen-free, RoHS-compliant materials make it suitable for demanding industrial environments. The compact 1.8 mm thickness and 61.2 mm height optimize space usage on DIN rails.

Suitable for

• Insulating and closing off WAGO 2002 Series terminal block assemblies
• Industrial control panels and electrical enclosures
• Building automation and distribution systems
• Applications requiring UL, CSA, and VDE approvals

Key specifications

• Product Type: End Plate
• Series: TOPJOB S
• Color: Grey
• Material: Polyamide 66 (PA 66)
• Flammability Rating: UL 94 V-0
• Thickness: 1.8 mm
• Height from DIN Rail: 61.2 mm
• Depth: 32.9 mm
• Operating Temperature: -35 to +105 °C
• Approvals: UL, CSA, VDE
• RoHS Compliant: Yes
• Halogen-free: Yes

Recommendations

For optimal performance, use with WAGO 2002 Series terminal blocks and ensure proper snap-on mounting on DIN rails. This end plate is ideal for new installations or as a replacement part in existing systems.
