WAGO 2002-475 Through Terminal Block, TOPJOB S, 2.5 mm², Gray, DIN Rail Mount

The WAGO 2002-475 is a high-quality through terminal block from the TOPJOB S series, designed for reliable and maintenance-free electrical connections. With push-in CAGE CLAMP® technology, it ensures fast, tool-free wiring for solid and stranded conductors. Ideal for industrial control cabinets and building installations, this terminal block offers a nominal voltage of 800 V and a nominal current of 24 A, meeting EN 60947-7-1 standards.

Advantages

Push-in connection technology reduces installation time by up to 50% compared to traditional screw terminals. The compact design saves space on DIN-35 rails, while the gray polyamide housing provides excellent insulation and durability. Rated impulse voltage of 8 kV and pollution degree 3 ensure reliable performance in demanding environments.

Suitable for

• Industrial control panels and switchgear
• Building automation and electrical distribution
• Machine wiring and junction boxes
• Lighting and power supply connections

Key specifications

• Series: TOPJOB S
• Type: Through Terminal Block
• Number of Potentials: 1
• Number of Connection Points: 2
• Connection Technology: Push-in CAGE CLAMP®
• Nominal Cross-Section: 2.5 mm² (12 AWG)
• Nominal Voltage (EN 60947-7-1): 800 V
• Nominal Current (EN 60947-7-1): 24 A
• Rated Impulse Voltage: 8 kV
• Pollution Degree: 3
• Mounting Type: DIN-35 Rail
• Color: Gray
• Insulation Material: Polyamide (PA)
• Stripping Length: 9 ... 11 mm
• Connectable Conductor Size (Solid): 0.25 ... 4 mm² (22 ... 12 AWG)
• Connectable Conductor Size (Stranded): 0.25 ... 4 mm² (22 ... 12 AWG)
• Connectable Conductor Size (Fine-stranded): 0.25 ... 2.5 mm² (22 ... 14 AWG)

Recommendations

For optimal performance, use with WAGO marking strips and end brackets. Ensure proper stripping length (9-11 mm) for secure connections. Suitable for use with copper conductors only.
