WAGO 2002-474 2-Conductor Through Terminal Block, 2.5 mm², 24 A, Gray, Push-in CAGE CLAMP

The WAGO 2002-474 is a high-quality 2-conductor through terminal block from the 2002 Series, designed for reliable and maintenance-free wiring in industrial and building installations. With a nominal cross-section of 2.5 mm² (12 AWG) and a rated current of 24 A, it is ideal for connecting solid and fine-stranded conductors. The Push-in CAGE CLAMP® connection technology ensures fast, tool-free wiring, saving time and labor costs.

Advantages

• Tool-free Push-in connection for solid conductors and ferruled fine-stranded conductors
• Compact design saves space on DIN-rail 35 x 15 / 35 x 7.5 mm
• High reliability with vibration-proof and maintenance-free connections
• Clear marking and color coding for easy identification
• Wide operating temperature range from -35 °C to +85 °C

Suitable for

• Industrial control cabinets
• Building automation systems
• Power distribution and junction boxes
• Lighting and HVAC systems
• Machine and plant engineering

Key specifications

• Connection Technology: Push-in CAGE CLAMP®
• Number of Conductors: 2
• Number of Potentials: 1
• Nominal Cross-Section: 2.5 mm² (12 AWG)
• Solid Conductor Size: 0.25 … 4 mm² (22 … 12 AWG)
• Fine-Stranded Conductor Size: 0.25 … 4 mm² (22 … 12 AWG)
• Fine-Stranded with Ferrule (Plastic Collar): 0.25 … 2.5 mm² (22 … 14 AWG)
• Strip Length: 9 … 11 mm (0.35 … 0.43 inch)
• Rated Voltage (EN 60947-7-1): 800 V
• Rated Impulse Voltage: 8 kV
• Rated Current (EN 60947-7-1): 24 A
• Pollution Degree: 3
• Overvoltage Category: III
• Insulating Material: Polyamide (PA 66)
• Color: Gray
• Mounting Type: DIN-rail 35 x 15 / 35 x 7.5
• Wiring Type: Side-entry wiring
• Operating Temperature: -35 … +85 °C
• Approvals: UL, CSA, VDE, EAC, KEMA/KEUR

Recommendations

For optimal performance, use with WAGO marking strips and accessories. Ensure proper strip length and conductor preparation for reliable connections.
