WAGO 2002-1404 Through Terminal Block, 2-Conductor, 800V, 24A, Gray, Push-in CAGE CLAMP

The WAGO 2002-1404 is a high-quality through terminal block designed for reliable and efficient electrical connections. Featuring the innovative Push-in CAGE CLAMP® connection technology, this terminal block ensures fast, tool-free wiring for solid and fine-stranded conductors. With a compact design and a rated voltage of 800V and current of 24A, it is ideal for a wide range of industrial and building automation applications.

Advantages

Tool-free push-in connection saves installation time and reduces labor costs. The compact 2-conductor design allows for space-saving wiring on DIN-35 rails. High-quality polyamide insulation ensures long-term reliability and safety. Rated impulse voltage of 8kV and pollution degree 3 provide robust performance in demanding environments.

Suitable for

• Industrial control panels
• Building automation systems
• Distribution boards
• Machine wiring
• Lighting control systems

Key specifications

• Terminal block type: Through terminal block
• Number of conductors: 2
• Connection technology: Push-in CAGE CLAMP®
• Nominal cross-section: 2.5 mm² (AWG 14)
• Rated voltage (EN): 800 V
• Rated current (EN): 24 A
• Rated impulse voltage: 8 kV
• Pollution degree: 3
• Insulating material: Polyamide (PA)
• Color: Gray
• Mounting type: DIN-35 rail
• Solid conductor size: 0.25 ... 4 mm² (22 ... 12 AWG)
• Fine-stranded conductor size: 0.25 ... 4 mm² (22 ... 12 AWG)
• Fine-stranded with ferrule size: 0.25 ... 2.5 mm² (22 ... 14 AWG)
• Stripping length: 9 ... 11 mm
• Operating temperature: -35 ... +85 °C
• Approvals: UL, CSA, VDE, IECEx, ATEX

Recommendations

For optimal performance, use with WAGO marking strips and end brackets. Ensure proper stripping length (9-11 mm) for reliable push-in connection. Suitable for use with ferrules on fine-stranded conductors.
