WAGO 2001-1207 2-Conductor Push-in Terminal Block, 1.5 mm², Gray, DIN Rail Mount

The WAGO 2001-1207 is a compact 2-conductor terminal block featuring the innovative Push-in CAGE CLAMP® connection technology. Designed for reliable and tool-free wiring, this terminal block is ideal for a wide range of industrial and building automation applications. With a nominal cross-section of 1.5 mm² (16 AWG) and a rated voltage of 800 V, it ensures safe and efficient electrical connections.

Advantages

Push-in CAGE CLAMP® technology allows for fast and secure wire termination without the need for special tools. The front-entry wiring design simplifies installation, while the compact dimensions (4.2 mm width, 50.8 mm height, 32.9 mm depth) save valuable space on the DIN rail. The gray polyamide housing offers high mechanical strength and a flammability rating of UL94 V0, ensuring long-term reliability.

Suitable for

• Industrial control panels
• Building automation systems
• Distribution boards
• Machine wiring

Key specifications

• Number of conductors: 2
• Connection technology: Push-in CAGE CLAMP®
• Nominal cross-section: 1.5 mm² (16 AWG)
• Nominal voltage (IEC): 800 V
• Nominal current (IEC): 17.5 A
• Mounting type: DIN-35 rail
• Color: Gray
• Insulating material: Polyamide (PA)
• Pollution degree: 3
• Rated impulse voltage: 8 kV
• Wire stripping length: 9 – 11 mm (0.35 – 0.43 inch)
• Solid conductor size: 0.14 – 1.5 mm² / 24 – 16 AWG
• Fine-stranded conductor size: 0.14 – 1.5 mm² / 24 – 16 AWG
• Fine-stranded with ferrule: 0.25 – 1.5 mm² / 22 – 16 AWG
• Operating temperature: -35 °C to +85 °C
• Flammability rating: UL94 V0
• Number of potentials: 1
• Wiring type: Front-entry wiring
• Actuation type: Push-in / Push-button

Recommendations

For optimal performance, use with WAGO marking accessories and appropriate DIN rail. Ensure proper wire stripping length for secure connections.
